Cisco Qsfp To 4xsfp10g Passive Copper Splitter Cable, 3m Qsfp-4sfp10g-cu3m=
Overview
The 40-Gigabit QSFP+ transceiver module is a hot-swappable, parallel fiber-optical module with four independent optical transmit and receive channels. These channels can terminate in another 40-Gigabit QSFP+ transceiver, or the channels can be broken out to four separate 10-Gigabit SFP+ transceivers. (See Figure 1.) The QSFP+ transceiver module connects the electrical circuitry of the system with either a copper or an optical external network. (See Figure 2 for a view of the optical QSFP+ transceiver.) The transceiver is used primarily in short reach applications in switches, routers, and data center equipment where it provides higher density than SFP+ modules.
Figure 1 40-Gigabit QSFP+ Transceiver Module (Copper)
| 1 | QSFP+ transceiver body | 3 | Pull tab |
| 2 | 10GBASE SFP+ transceivers |
Figure 2 40-Gigabit QSFP+ Transceiver Module (Optical)
| 1 | 40GBASE QSFP+ transceiver body | 3 | Electrical connection to the module circuitry |
| 2 | Bail-clasp latch |
| QSFP-4SFP10G-CU3M= | Cisco 40GBASE-CR4 QSFP+ to 4 10GBASE-CU SFP+ passive direct-attach copper transceiver assembly, 3 meter |
| Basic | |
|---|---|
| Brand Name: | Cisco |
| Cable Length: | 3 m |
| Cable Type: | QSFP+/SFP+ |
| Connector on First End: | QSFP+ Network |
| Connector on Second End: | SFP+ - Network |
| Product Type: | Network Cable |
| General Information | |
|---|---|
| Brand Name: | Cisco |
| Manufacturer Part Number: | QSFP-4SFP10G-CU3M= |
| Manufacturer Website Address: | http://www.cisco.com/c/en_au |
| Manufacturer: | Cisco Systems, Inc |
| Product Model: | QSFP-4SFP10G-CU3M= |
| Product Name: | QSFP+/SFP+ Network Cable |
| Product Type: | Network Cable |
