Qnap Qsw-1105-5T: 5 Port 2.5Gbps Auto Negotiation (2.5G/1G/100M), Unmanagement Switch, 2y Rtb QSW-1105-5T
SKU
306297
Brand
MPN
QSW-1105-5T
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$123.00
Buy Now And Earn 123 Reward Points!
QNAP QSW-1105-5T: 5 port 2.5Gbps auto negotiation (2.5G/1G/100M), unmanagement switch
| PoE | None |
|---|---|
| SKU | QSW-1105-5T |
| Brand | QNAP |
| Color | Black |
| Model | QSW-1105-5T |
| Notes | Does not provide PoE; no Kensington lock port reported |
| Ports | 5 x RJ45 |
| Weight | Approx. 0.58 kg / 1.27 lb / 577 g |
| Chipset | Broadcom BCM53161 |
| Cooling | Fanless (passive cooling with internal heatsink) |
| Category | Networking |
| Warranty | Limited warranty: 2 years (parts and labor) |
| Management | Unmanaged (plug-and-play) |
| Description | Compact, fanless 5-port unmanaged multi-gig switch that upgrades networks to 2.5GbE speeds with plug-and-play simplicity. The QSW-1105-5T provides five RJ45 2.5GbE auto-negotiating ports (2.5/1/0.1 Gbps), network loop detection and blocking, 9KB jumbo frame support, a 16K MAC address table and 25 Gbps switching capacity (12.5 Gbps non-blocking throughput). Built with a metal, ventilated desktop chassis and passive cooling (single heatsink), it includes an external power adapter and mounting/desk/foot accessories for flexible deployment. |
| Form Factor | Desktop |
| Port Speeds | Auto-negotiation 2.5 Gbps / 1 Gbps / 100 Mbps (supports 10/100/1000/2.5G links) |
| Power Supply | External power adapter (100–240 VAC, 50/60 Hz) |
| Product Type | Unmanaged 2.5GbE Multi-Gig Switch |
| Sub-Category | Switches and Hubs |
| Product Title | QNAP QSW-1105-5T 5-Port Unmanaged 2.5GbE Switch |
| Certifications | CE, FCC, VCCI, BSMI, CCC, KCC, LVD, AS/NZS (various regional certifications listed) |
| LED Indicators | Per-port Speed/Link/Activity; Loop LED; System Power/Status |
| Loop Detection | Yes — network loop detection and automatic blocking/locking of looped ports |
| Other Features | Compatible with Cat5e cabling; per-port auto-negotiation; near-silent operation |
| Chassis Material | Metal (ventilated desktop chassis) |
| Mounting Options | Rubber foot pads; mounting points for wall/desk/conference table |
| Package Contents | QSW-1105-5T switch, power supply, bracket screws/anchors, foot pads, Quick Installation Guide |
| Status Indicators | Power, Status, Loop, Link/Activity/Speed |
| Operating Humidity | 10% to 90% (non-condensing) |
| Switching Capacity | 25 Gbps |
| Jumbo Frame Support | 9 KB (9000 bytes) |
| Supported Standards | IEEE 802.3, IEEE 802.3u (100BASE-T), IEEE 802.3ab (1000BASE-T), IEEE 802.3bz (2.5GBase-T), IEEE 802.3x (Full-Duplex Flow Control) |
| Included Accessories | Power adapter, foot pads (4), mounting screws/anchors |
| Flow Control / Duplex | Full-duplex flow control supported |
| Max Power Consumption | 12 W |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Dimensions (W x D x H) | 180 x 145 x 34 mm (7.09 x 5.71 x 1.34 inches) |
| MAC Address Table Size | 16K entries |
| Non-Blocking Throughput | 12.5 Gbps |
| Manufacturer Part Number | QSW-1105-5T-US |
QNAP QSW-1105-5T: 5 port 2.5Gbps auto negotiation (2.5G/1G/100M), unmanagement switch, 2y RTB
