Aruba 6200M 24G CL4 Poe 4SFP+ Sw R8Q68A
SKU
404412
Brand
MPN
R8Q68A
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$9,070.00
Buy Now And Earn 9070 Reward Points!
HPE Aruba 6200M 24G Class4 PoE 4SFP+ - Switch - L3 - Managed - 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) - front and side to back - rack-mountable - PoE+ (740 W)
| Ports | 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) |
| Power | AC 100-120/200-240 V (50/60 Hz) |
| Weight | 5.83 kg |
| Subtype | Gigabit Ethernet |
| Capacity | Switched virtual interfaces (SVIs): 128 ? IPv4 host table capacity: 8000 ? IPv6 host table capacity: 8000 ? IPv4 routes (Unicast): 2000 ? IPv6 routes (Unicast): 2000 ? IGMP groups: 1000 ? MLD groups: 1000 ? IPv4 ACL entries (ingress): 1000 ? IPv6 ACL entries (ingress): 1000 ? MAC ACL entries (ingress): 1000 ? IPv4 ACL entries (egress): 512 ? IPv6 ACL entries (egress): 256 ? MAC ACL entries (egress): 512 ? Packet buffer size: 8 MB |
| Features | DHCP support, VLAN support, auto-uplink (auto MDI/MDI-X), Syslog support, IPv6 support, sFlow, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), Per-VLAN Spanning Tree Plus (PVST+), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Deficit Weighted Round Robin (DWRR), LLDP support, Management Information Base (MIB), Multiple VLAN Registration Protocol (MVRP), packet storm protection, Class of Service (CoS), Type of Service (ToS), Bridge protocol data unit (BPDU), Virtual Extensible LAN (VXLAN), Network Timing Protocol (NTP), Protocol Independent Multicast (PIM), Rapid Reconfiguration of Spanning Tree (RSTP), Aruba Virtual Switching Framework (VSF), dynamic IPv6 lockdown, ND snooping |
| PoE Budget | 740 W |
| Device Type | Switch - 24 ports - L3 - Managed - stackable |
| Performance | Switching capacity: 128 Gbps ? Throughput: 95.2 Mpps ? Latency (1 Gbps): 2.28 ?s ? Latency (10 Gbps): 1.46 ?s ? Stacking bandwidth: 40 Gbps |
| Enclosure Type | Front and side to back rack-mountable 1U |
| Power Redundancy | Optional |
| Routing Protocol | OSPF, IGMPv2, IGMP, VRRP, PIM-SM, PIM-DM, IGMPv3, ECMP, MLD, MSTP, RSTP, STP |
| Dimensions (WxDxH) | 44.2 cm x 38.5 cm x 4.4 cm |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at |
| Jumbo Frame Support | 9220 bytes |
| Product Description | HPE Aruba 6200M 24G Class4 PoE 4SFP+ - switch - 24 ports - Managed - rack-mountable |
| Manufacturer Warranty | Limited lifetime warranty |
| Power Over Ethernet (PoE) | PoE+ |
| Remote Management Protocol | SNMP, RMON, SNMP 3, SNMP 2c, TFTP, SSH, CLI, SFTP |
HPE Aruba 6200M 24G Class4 PoE 4SFP+ - Switch - L3 - Managed - 24 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink / stacking) - front and side to back - rack-mountable - PoE+ (740 W)
