REYEE Ruijie Reyee AirMetro 460G 5GHz PTMP CPE - 867Mbps, 23dBi, 15KM, GE RG-AIRMETRO460G
The Ruijie Reyee RG-AirMetro460G is a high performance wireless bridge designed for long range point-to-point (PTP) and point-to-multipoint (PTMP) connections, particularly in outdoor settings. It utilizes the 5GHz frequency band and supports the IEEE 802.11ac (Wi-Fi 5) standard, enabling data transmission rates up to 867Mbps. The device is equipped with a 23dBi directional antenna, allowing for connections up to 15 kilometers in ideal conditions. It is also built to withstand harsh weather with an IP65 rating and features surge and ESD protection.
Highlights
- Maximum PTP Distance: 15KM
- Easy PTMP Pairing in 30 Secs
- 24V Passive PoE
- IP65 Rated
- 6kV Surge Protection and ±24 kV ESD
- 220.32km/h Wind Survivability
- Easy remote configuration, monitoring and management via the free Ruijie Cloud and App
- 3 Year Limited Warranty
| Dimensions | 368.5mm x 271mm (Diameter x Length, including mounting kit) |
| Working Distance | 15KM |
| Gain | 23dBi |
| Angle | H: 9°, V: 9° |
| Capacity | 5GHz, 867Mbps |
| Port | 1x 10/100/1000Mbps |
| IP Rating | IP65 |
| Operation Temperature* | –40°C to +70°C |
| ESD | ±24kV Contact/ Air |
| Surge Protection | 6kV |
| Power | 24V Passive PoE |
| LED | 3 Signal Strength LED | 1 LAN LED | 1 System LED |
| Pairing Method | One touch pairing in 30 secs | App pairing in 2 mins |
| Certification | CE |
| Warranty | 3 Year Limited Warranty |
| Configuration/Monitoring/Management | Ruijie Cloud and App (Free) |
