PATRIOT 13.8V DC 8A ADJUSTABLEPOWER SUPPLY 2YRS S4715A
SKU
401941
Brand
MPN
ACPS13.8
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$215.00
Buy Now And Earn 215 Reward Points!
Looking for 12v DC power supply? Look no further, OPS-12V-8A, adjustable 13.5VDC 8A Power Supply.
FEATURES:
- Extremely compact and efficient (small footprint)
-1.2A charger able to charge up to 4 x 12V 7AH battery
- Mains fail relay contact and LED
- Low battery relay contact and LED-
- Reverse polarity protection on battery terminal
- Australian 10A plug on input
- Parallel configuration to increase current output possible
| Input Voltage | 85 ~ 264VAC |
| Output Voltage Range (Adjustable) | 11.2 ~ 13.8VDC (Preset @ 12VDC) |
| Output Voltage Tolerance | ± 1% |
| Max Power Output Current | 8.5A |
| Power Supply Protection | Short Circuit, Overload and Over Voltage |
| Australian Regulatory Compliance Mark (RCM) | N12754 |
| Dimensions / Weight | 260x130x60mm / 1.2Kg |
| Contacts | Mains Failure & Low Battery |
PATRIOT 13.8V DC 8A ADJUSTABLEPOWER SUPPLY 2YRS
