Features:
Universal input
Japanese Capacitor
High efficiency 87%
Meet CEC Level V, ErP Lot 7, Energy Star EPS2.0
Over voltage protection
Over current protection
Short circuit protection
Over Thermal protection
No load consumption≦0.5W
Output Specifications:

Model

Output power

Min. Load

Max. Load

Total power

Efficiency

SSA-1201-24

24V

0A

5

120W

87%

Dimension:
L174 × W65 × H37 mm (L6.85 × W2.56 × H1.46 inch)
General Specifications:
Input voltage range: 90~264 Vac
Input frequency: 47~63 Hz
Input current: 2A (rms)
Efficiency: ≧87% Average
Leakage current: 3.5mAa max.
Safety:

Safety

EMI/EMC

CEC

CB

CUL

UL

CCC

DEMKO

FIMKO

NEMKO

SEMKO

TUV

cTUVus

VDE

PSE

BSMI

C-tick

CE

FCC

V

V

V

V

V

V

V

V

V

V

(V = certificate ready ; P = certificate pending; V * = not apply to all models )
