Apc - Schneider EASY UPS SMV 750VA 230V WITHBATTERY BACKUP + SURGE PROTECTIO SMV750CAI
SKU
370807
Brand
MPN
SMV750CAI
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$343.00
Buy Now And Earn 343 Reward Points!
SMV750CAI Features
Key Features
Run time for load
Min-max: 53-525 W
W
6m 50s
Max. Capacity Used
Output power capacity
525 Watts / 750VA
Output Connections
(6) IEC 320 C13 (Battery Backup)
(6) IEC 60320 C13 (Battery Backup)
Nominal Output Voltage
230V
Nominal Input Voltage
230V
Input Connections
IEC 60320 C14
APC Easy UPS SMV 750VA 230V
Easy UPS provides power protection for unstable power conditions, ensuring consistent and reliable connectivity at the most critical moments.
Includes: Documentation CD, USB cable, User manual
- Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
- Cold-start capable
Provides temporary battery power when the utility power is out.
- Intelligent SmartSlot
Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
- LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
- Pure sine wave output on battery
Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
Easy UPS Features & Benefits
Protection
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes .
Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
Safety
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Availability
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Features
Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.
Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
Cold-start capable
Provides temporary battery power when the utility power is out.
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Manageability
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Controls/Indicators
| Status Indicators |
LCD Graphics Display:
LED Indicators:
|
Interfaces/Ports
| Serial Port | Yes |
| USB (HID Compliant) Port | Yes |
Management
| Alarm | Low Battery |
| On Battery | |
| Overload |
Physical Characteristics
| Weight (Approximate) | 13.60 kg |
| Form Factor | Tower |
| Height | 220 mm |
| Width | 160 mm |
| Depth | 410 mm |
Battery Information
| Battery Chemistry | Lead Acid |
| Battery Size | 12V |
| Battery Capacity | 7000 mAh |
| Number of Batteries | 2 |
| Battery Characteristics | Maintenance-free, Sealed, Leak-proof |
| Typical Battery Recharge Time | 4 Hour |
Environmental Conditions
| Sound Emission | 45 dB(A) |
| Maximum Operating Temperature | 40°C |
| Maximum Operating Elevation | 3 km |
| Maximum Storage Elevation | 3 km |
| Operating Humidity | 0% - 95% |
| Storage Relative Humidity | 0% - 95% |
| Storage Temperature | -10°C - 40°C |
General Information
| Product Type | Line-interactive UPS |
| Manufacturer Part Number | SMV750CAI |
| Manufacturer Website Address | http://www.schneider-electric.com.au |
| Manufacturer | Schneider Electric SA |
| Product Name | Easy UPS 750VA Tower UPS |
| Product Line | Easy UPS |
| Brand Name | APC by Schneider Electric |
Power Description
| Input Voltage | 230 V AC |
| Output Voltage | 230 V AC |
| Load Capacity | 750 VA/525 W |
| Waveform Type | Sine Wave |
| Input Voltage Range | 160 V AC 295 V AC |
| Output Frequency | 60 Hz |
| Input Frequency | 65 Hz |
Technical Information
| Application/Usage | SOHO Office |
| Electronic | |
| Office | |
| Computer | |
| Overload Protection | Yes |
| Plug/Connector Type | IEC 60320 C14 |
| Receptacle Type | IEC 60320 C13 |
| AVR | Yes |
| Transfer Time | 2 ms |
| Receptacle Detail | 6 x IEC 60320 C13 |
