Startech 2 Port Ftdi Usb To Serial Rs232 Adapter Cable With Com Retention - Usb To Db9 - Usb To ICUSB2322F
QUICK OVERVIEW
Enlarge
2 Port FTDI USB to Serial RS232 Adapter Cable with COM Retention - USB to DB9 -
USB to Serial Port
by Startech
Category: Connectivity Devices
Sub Category: Serial/Parallel & I/O Cards
Product Type: Multiport Serial Devices & Cables
The ICUSB2322F 2-Port USB to Serial RS232 Adapter Cable with FTDI chipset and
COM Retention converts an available USB 1.1 or 2.0 port into 2 RS232 serial DB9
ports to connect, monitor and control your serial devices.This compact adapter
features COM retention, allowing the same COM port values to automatically be
re-assigned to the port if the cable is disconnected and re-connected to the
host computer, or if the system is rebooted. Unlike most USB-serial adapters,
this one uses the FTDI chipset, which supports additional customization,
advanced features, and compatibility not necessarily offered by other
solutions.This USB-serial adapter is compatible with a broad list of Operating
Systems, including Windows, Windows CE, Mac OS and Linux, making this product
the perfect solution for integrating into mixed environments.Backed by a
StarTech.com 2-year warranty and free lifetime technical support.
Brand Name: StarTech.com
Cable Length: 1.83 m
Cable Type: Serial
Colour: Black
Connector on First End: 1 x Type A Male USB
Connector on Second End: 2 x DB-9 Male Serial
Product Type: Data Transfer Cable
| Connector(s) | |
| Connector Type(s) | DB-9 (9 pin, D-Sub) Male |
| USB Type-A (4 pin) USB 2.0 Male | |
| Environmental | |
| Humidity | 5~95% RH |
| Operating Temperature | 0?C to 55?C (32?F to 131?F) |
| Storage Temperature | -20?C to 85?C (-4?F to 185?F) |
| Hardware | |
| Bus Type | USB 2.0 |
| Chipset ID | FTDI - FT2232D |
| Interface | Serial |
| Port Style | Cable Adapters |
| Ports | 2 |
| Packaging Information | |
| Shipping (Package) Weight | 0.2 kg [0.5 lb] |
| Performance | |
| Data Bits | 7, 8 |
| FIFO | 128 Bytes |
| Max Baud Rate | 921.6 Kbps |
| Parity | None, Odd, Even, Mark,Space |
| Serial Protocol | RS-232 |
| Stop Bits | 1, 2 |
| Physical Characteristics | |
| Cable Length | 1.8 m [6 ft] |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 20 mm [0.8 in] |
| Product Length | 2133 mm [84 in] |
| Product Weight | 159 g [5.6 oz] |
| Product Width | 45 mm [1.8 in] |
| Power | |
| Power Source | USB-Powered |
| Software | |
| OS Compatibility | Windows? CE (4.2, 5.0, 6.0), XP Embedded, 98SE, 2000, XP, Vista, 7, 8, 8.1, 10 Windows Server? 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS? 10.6 to 10.13 Linux 2.4.x to 4.11.x LTS Versions only |
| Special Notes / Requirements | |
| System and Cable Requirements | One available USB 1.1 (or better) port |
| What's in the Box | |
| Included in Package | 2 Port USB to RS-232 Serial Adapter |
| Driver CD | |
| Instruction Manual | |
| Wall Mounting Kit | |
The ICUSB2322F 2-Port USB to Serial RS232 Adapter Cable with FTDI chipset and COM Retention converts an available USB 1.1 or 2.0 port into 2 RS232 serial DB9 ports to connect, monitor and control your serial devices.
This compact adapter features COM retention, allowing the same COM port values to automatically be re-assigned to the port if the cable is disconnected and re-connected to the host computer, or if the system is rebooted. Unlike most USB-serial adapters, this one uses the FTDI chipset, which supports additional customization, advanced features, and compatibility not necessarily offered by other solutions.
This USB-serial adapter is compatible with a broad list of Operating Systems, including Windows®, Windows CE, Mac OS and Linux, making this product the perfect solution for integrating into mixed environments.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
