Startech 2 Port Usb Displayport Cable Kvm Switch With Audio And Remote Switch - Usb Powered Kvm With Displayport - Dual Port Displayport Kvm Sv211dpua
QUICK OVERVIEW
2 Port USB DisplayPort Cable KVM Switch with Audio and Remote Switch - USB
Powered KVM with DisplayPort - Dual Port DisplayPort KVM Switch - Two Port DP
KVM Switch
by Startech
Category: Connectivity Devices
Sub Category: Switching Devices
Product Type: Kvm Switches & Components
Control two DisplayPort®, USB equipped PCs with a single monitor, keyboard,
mouse and audio peripheral set. The SV211DPUA 2-Port DisplayPort® Cable KVM
Switch with Audio and Remote Switching Control lets you control two DisplayPort,
USB equipped PCs with a single monitor, keyboard, mouse and audio peripheral
set.
To help organize your desk without sacrificing work space, this compact
DisplayPort USB KVM features integrated cables that can be connected directly to
your system, while leaving a minimal footprint. The switch features a remote
push-button on a 1.5 meter (5ft) integrated cable that can be placed in an
easily accessible location, as well as keyboard hot-keys, and PC or Mac®
compatible software for switching between systems. To eliminate the need for a
bulky external power adapter and wall outlet, the DisplayPort KVM switch is
USB-powered.
This KVM with DisplayPort video capability offers support for resolutions up to
2560x1600 for the ability to drive a large DisplayPort display for applications
that require high graphical output.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Brand Name: StarTech.com
Number of Computers Supported: 2
Number of Local Users Supported: 1
Product Type: KVM Switchbox
USB: Yes
Connector(s) | |
Console Interface(s) | 3.5 mm Mini-Jack (3 Position) |
DisplayPort (20 pin) Female | |
USB Type-A (4 pin) USB 2.0 | |
Host Connectors | 3.5 mm Mini-Jack (3 Position) Male |
DisplayPort (20 pin) Male Latching | |
USB Type-A (4 pin) USB 2.0 Male | |
Environmental | |
Humidity | 0~90% RH Non-Condensing |
Operating Temperature | 0?C to 40?C (32?F to 104?F) |
Storage Temperature | -20?C to 60?C (4?F to 140?F) |
Hardware | |
Audio | Yes |
Cables Included | Yes |
Daisy-Chain | No |
KVM Ports | 2 |
Number of Monitors Supported | 1 |
PC Interface | USB |
PC Video Type | DisplayPort |
Rack-Mountable | No |
Indicators | |
LED Indicators | PC Selection indictor |
Packaging Information | |
Shipping (Package) Weight | 550 g [19.4 oz] |
Performance | |
Audio Specifications | Analog (3.5mm) and DisplayPort audio supported |
Hot-Key Selection | Yes |
IP Control | No |
On-Screen Display | No |
Port Selection Support | Push Button, Hotkeys, and Software |
Physical Characteristics | |
Cable Length | 850 mm [33.5 in] |
Color | Black |
Enclosure Type | Plastic |
Product Height | 23 mm [0.9 in] |
Product Length | 88 mm [3.5 in] |
Product Weight | 400 g [14.1 oz] |
Product Width | 66 mm [2.6 in] |
Power | |
Power Source | USB-Powered |
Software | |
OS Compatibility | Windows? 2000, XP, Vista, 7, 8, 8.1, 10 Windows Server? 2003, 2008 R2, 2012, 2016 Mac OS 10.x (Tested up to 10.9), 9.x |
Special Notes / Requirements | |
Note | If you intend to convert the DisplayPort KVM to work with different video sources or displays such as HDMI or VGA, active adapters are required |
OS Compatibility refers to KVM software only - the KVM itself can be used without software on any platform | |
What's in the Box | |
Included in Package | Instruction Manual |
KVM Switch | |
Software CD |
The SV211DPUA 2-Port DisplayPort® Cable KVM Switch with Audio and Remote Switching Control lets you control two DisplayPort, USB equipped PCs with a single monitor, keyboard, mouse and audio peripheral set.
To help organize your desk without sacrificing work space, this compact DisplayPort USB KVM features integrated cables that can be connected directly to your system, while leaving a minimal footprint. The switch features a remote push-button on a 1.5 meter (5ft) integrated cable that can be placed in an easily accessible location, as well as keyboard hot-keys, and PC or Mac® compatible software for switching between systems. To eliminate the need for a bulky external power adapter and wall outlet, the DisplayPort KVM switch is USB-powered.
This KVM with DisplayPort video capability offers support for resolutions up to 2560x1600 for the ability to drive a large DisplayPort display for applications that require high graphical output.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
