Startech 5m Usb 2.0 Active Extension Cable M/ F - 5 Meter Usb A Male To Usb A Female Usb 2.0 Repeater/ USB2AAEXT5M
QUICK OVERVIEW
5m USB 2.0 Active Extension Cable M/F - 5 meter USB A Male to USB A Female
USB 2.0 Repeater / Extender Cable - Black - 15ft
by Startech
Category: Cables
Sub Category: Computer Cables & Adapters
Product Type: Usb Cables & Adapters
Extend the distance between a computer and a USB 2.0 device by 5 meters. The
USB2AAEXT5M 5m Active USB 2.0 Extension Cable offers one USB-A male connector
and one USB-A female connector, and provides an active extension of USB 2.0
devices of up to 5-meters (15-feet).
An all-in-one cable for overcoming distance restrictions as well as power source
limitations, the active USB 2.0 extension cable incorporates bus-powered active
circuitry to ensure performance beyond the length limits of standard USB cables.
Plus you can daisy chain 4 cables for a total USB extension of up to 20-meters.
If necessary, the USB device can be powered from a wall outlet using the
Universal AC power adapter (provided with the cable).
The USB2AAEXT5M repeater cable supports the full USB 2.0 bandwidth of 480 Mbps,
and is backed by StarTech.com's 2-year Warranty.
Brand Name: StarTech.com
Cable Length: 5 m
Cable Type: USB
Colour: Black
Connector on First End: 1 x Type A Male USB
Connector on Second End: 1 x Type A Female USB
Packaged Quantity: 1
Product Type: Data Transfer Cable
| Physical Characteristics | |
| Product Weight | 286 g [10.1 oz] |
| Product Width | 16.4 mm [0.6 in] |
| Wire Gauge | 24 AWG |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.35 A |
| Input Voltage | 110V-240V AC |
| Output Current | 1A |
| Output Voltage | 5 DC |
| Plug Type | H |
| Power Consumption (In Watts) | 5 |
| Power Source | AC Adapter Included |
| Special Notes / Requirements | |
| Note | Cascade up to 4 USB2AAEXT5M cables together for further extension |
| What's in the Box | |
| Included in Package | 5m USB 2.0 Active Extension Cable - M/F |
| Plug Adapters for North America, UK, Europe, and Australia | |
| Universal Power Adapter | |
| Physical Characteristics | |
| Product Length | 5 m [16.4 ft] |
| Product Height | 9.2 mm [0.4 in] |
| Connector Style | Straight |
| Color | Black |
| Cable Length | 5 m [16.4 ft] |
| Packaging Information | |
| Shipping (Package) Weight | 474 g [16.7 oz] |
| Package Quantity | 1 |
| Hardware | |
| Connector Plating | Nickel |
| Cable Shield Type | Aluminum-Mylar Foil with Braid |
| Cable Jacket Type | PVC - Polyvinyl Chloride |
| Connector(s) | |
| Connector B | USB Type-A (4 pin) USB 2.0 Female |
| Connector A | USB Type-A (4 pin) USB 2.0 Male |
The USB2AAEXT5M 5m Active USB 2.0 Extension Cable offers one USB-A male connector and one USB-A female connector, and provides an active extension of USB 2.0 devices of up to 5-meters (15-feet).
An all-in-one cable for overcoming distance restrictions as well as power source limitations, the active USB 2.0 extension cable incorporates bus-powered active circuitry to ensure performance beyond the length limits of standard USB cables. Plus you can daisy chain 4 cables for a total USB extension of up to 20-meters.
If necessary, the cable can be powered from a wall outlet using the Universal AC power adapter that was provided with the cable – this will allow you to use USB bus-powered devices that may require extra power.
The USB2AAEXT5M repeater cable supports the full USB 2.0 bandwidth of 480 Mbps, and is backed by StarTech.com's 2-year Warranty.
