Startech Mini Displayport To Vga Video Adapter Converter 1920x1200 - White Mini Dp To Vga Adapter
QUICK OVERVIEW
Connect a VGA display to a Mini- DisplayPort®- equipped PC or Mac® computer.
The MDP2VGAW Mini- DisplayPort® to VGA Adapter (White) offers an easy-to-use
VGA/Mini- DisplayPort link that enables you to connect a VGA computer monitor to
a device with a Mini-DisplayPort output (such as a laptop video out port) or
video card.
The adapter cable is compatible with Intel® Thunderbolt™, when connected
directly to a supporting DisplayPort over Thunderbolt I/O port. Plus, because
the converter cable supports video resolutions up to 1920x1200 you can convert a
Mini DisplayPort video source to a VGA monitor without sacrificing video
quality.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Name MDP2VGAW Mini DisplayPort to VGA M/F Video Adapter White
Product Type Video Cable
Cable Type DisplayPort/VGA
Color White
Cable Length 4.72"
Connector on First End 1 x 20-pin Mini DisplayPort Male Digital Audio/Video
Connector on Second End 1 x 15-pin HD-15 Female VGA
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Device Supported Video Device
Monitor
Projector
TV
Certifications & Standards
FCC
CE
Conductor Copper
Material Plastic
Additional Information
Simple to use, small form factor converter makes Mini DisplayPort backward
compatible with your existing VGA display or projector
No software or driver installation required, providing a simple plug and play
solution
| Connector(s) | |
| Connector A | Mini-DisplayPort (20 pin) Male |
| Connector B | VGA (15 pin, High Density D-Sub) Female |
| Environmental | |
| Humidity | 40~85% RH |
| Operating Temperature | 0?C to 60?C (32?F to 140?F) |
| Storage Temperature | -10?C to 70?C (14?F to 158?F) |
| Hardware | |
| Active or Passive Adapter | Active |
| Adapter Style | Adapters |
| Audio | No |
| Converter Type | Format Converter |
| Industry Standards | DisplayPort 1.1a |
| Packaging Information | |
| Shipping (Package) Weight | 42 g [1.5 oz] |
| Performance | |
| Maximum Analog Resolutions | 1920x1200 |
| Physical Characteristics | |
| Cable Length | 120 mm [4.7 in] |
| Color | White |
| Enclosure Type | Plastic |
| Product Height | 15 mm [0.6 in] |
| Product Length | 180 mm [7.1 in] |
| Product Weight | 31 g [1.1 oz] |
| Product Width | 45 mm [1.8 in] |
| What's in the Box | |
| Included in Package | Mini DisplayPort? to VGA adapter |
The MDP2VGAW Mini-DisplayPort® to VGA Adapter (White) offers an easy-to-use VGA/Mini-DisplayPort link that enables you to connect a VGA computer monitor to a device with a Mini-DisplayPort output (such as a laptop video out port) or video card.
The adapter cable is compatible with Intel® Thunderbolt™, when connected directly to a supporting DisplayPort over Thunderbolt I/O port. Plus, because the converter cable supports video resolutions up to 1920x1200 you can convert a Mini DisplayPort video source to a VGA monitor without sacrificing video quality.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
