Startech Usb 3.0 To Dvi/ Vga External Video Card Multi Monitor Adapter - 2048x1152 - Usb 3.0 Graphics
QUICK OVERVIEW
Connect a DVI display through SuperSpeed USB 3.0, for an accelerated external
multi-monitor solution at resolutions up to 2048x1152. The USB32DVIPRO USB 3.0
to DVI Adapter turns an available USB 3.0 port into a DVI output, with high
resolution 2048x1152 video support - a convenient external video solution that
makes it easy to add multi-monitor capability to a USB 3.0-enabled desktop or
laptop computer (optimal performance from USB 3.0, backward compatible with USB
2.0).
Leveraging the high-bandwidth (5 Gbps) SuperSpeed USB 3.0 interface, the adapter
functions as a external graphics card to deliver smooth, high-resolution content
to your DVI or VGA-capable display (DVI to VGA Adapter included). The adapter
can be used to mirror your primary desktop, showing the same image on each
display, or to extend your desktop to double your workspace and increase your
productivity.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Name USB32DVIPRO USB 3.0 to DVI/VGA F/M Extended Video Card Multi
Monitor
Product Type Graphic Adapter
Maximum Resolution 2048 x 1152
Standard Memory 512 MB
Host Interface USB 3.0
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Analog Signal Yes
Digital Signal Yes
DVI Yes
Number of DVI Outputs 1
Height 0.6"
Memory Technology DDR2 SDRAM
Form Factor External
Length 3.1"
Certifications & Standards
FCC
CE
Platform Supported PC
System Requirements 1~2 USB Displays
Office Application:
CPU: i3 Dual core 2.8GHz
RAM: 2GB or higher
Full HD Video:
CPU: Quad Core 2.4GHz or Higher (i5 recommended)
RAM: 4GB or higher
Operating System(s):
Windows Vista (32/64 bit)
Windows 7 (32/64 bit)
Windows 8
| Performance | |
| Maximum Analog Resolutions | 2048x1152 |
| Maximum Digital Resolutions | 2048x1152 |
| MTBF | 90,577 hours |
| Note | Note: If using OS X 10.8, Apple update 10.8.3 must be installed before installing DisplayLink software. 10.8.3 fixes several serious OS X bugs exposed when DisplayLink software is installed. |
| Supported Resolutions | Widescreen(16/32 bit): 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720 Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480 |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Cable Length | 152.5 mm [6 in] |
| Color | Black |
| Enclosure Type | Plastic |
| Product Height | 15.5 mm [0.6 in] |
| Product Length | 78 mm [3.1 in] |
| Product Weight | 300 g [10.6 oz] |
| Product Width | 43.5 mm [1.7 in] |
| Power | |
| Power Source | USB-Powered |
| Software | |
| OS Compatibility | Windows? 2000, XP, Vista, 7, 8, 8.1, 10 MacOS? 10.6 to 10.13 Ubuntu 14.04, 16.04 ChromeOS 55+ |
| Special Notes / Requirements | |
| Note | Connect a maximum of five USB32DVIPRO adapters on a single PC - See manual for system requirements |
| System and Cable Requirements | Office Application: CPU: i3 Dual core 2.8GHz RAM: 2GB or higher Full HD Video: CPU: Quad Core 2.4GHz or Higher (i5 recommended) RAM: 4GB or higher |
| What's in the Box | |
| Included in Package | Driver CD |
| DVI to VGA Adapter | |
| Installation guide | |
| USB 3.0 to DVI Adapter | |
| Performance | |
| General Specifications | This USB video adapter uses a DisplayLink family chipset. If you?re connecting this device to a computer along with additional USB video adapters or docking stations, please avoid using devices with a Trigger or Fresco family chipset. |
| Packaging Information | |
| Shipping (Package) Weight | 0.2 kg [0.5 lb] |
| Hardware | |
| USB Pass-Through | No |
| Output Signal | DVI-I (DVI Digital/Analog) |
| Memory | 512MB DDR2 SDRAM |
| Chipset ID | DisplayLink - DL-3100 |
| Audio | Yes |
| Environmental | |
| Storage Temperature | -10?C to 80?C (14?F to 167?F) |
| Operating Temperature | 10?C to 40?C (50?F to 194?F) |
| Humidity | <85% RH Non-Condensing |
| Connector(s) | |
| Connector B | DVI-I (29 pin) Female |
| Connector A | USB Type-A (9 pin) USB 3.0 Male |
The USB32DVIPRO USB 3.0 to DVI Adapter turns an available USB 3.0 port into a DVI output, with high resolution 2048x1152 video support - a convenient external video solution that makes it easy to add multi-monitor capability to a USB 3.0-enabled desktop or laptop computer (optimal performance from USB 3.0, backward compatible with USB 2.0).
Leveraging the high-bandwidth (5 Gbps) SuperSpeed USB 3.0 interface, the adapter functions as a external graphics card to deliver smooth, high-resolution content to your DVI or VGA-capable display (DVI to VGA Adapter included). The adapter can be used to mirror your primary desktop, showing the same image on each display, or to extend your desktop to double your workspace and increase your productivity.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Recommended System Requirements:CPU: Quad Core 2.4GHz or Higher (i5 recommended)
RAM: 4GB or higher
