Connect an HDMI® and DVI-I-equipped display through a USB 3.0 port, for a 1080p HD external multi-monitor solution
With two video output ports, the dual head design of the adapter offers a compact multi-monitor solution across both HDMI® and DVI technology
SuperSpeed USB 3.0 to HDMI/DVI conversion delivers improved bandwidth compared to a USB 2.0 connection for smoother high-definition video content
The adapter is installed externally, through USB, which enables you to add graphics capability to your system without opening the case or voiding system warranties
SuperSpeed USB 3.0 (5 Gbps) Interface, backward compatible with USB 2.0
Supports resolutions up to 1920x1080p (Full HD) and 2048x1152
Quick, easy installation
Dual Head design supports both HDMI® and DVI-I simultaneously (DVI to VGA adapter included for VGA monitors)
USB-powered - No external power adapter required
Choose between Mirrored, Extended or Primary display configurations
Driver software supports display rotation
Supports the Windows® Aero interface
Supports 5.1 channel surround sound audio (HDMI only)
Supports the use of multiple USB32HDDVII adapters on a single system (up to 3), for up to 6 additional monitors
Connect an HDMI® and DVI-I-equipped display through a USB 3.0 port, for a 1080p HD external multi-monitor solution
Features
Connect an HDMI and DVI-I-equipped display through a USB 3.0 port, for a 1080p HD external multi-monitor solution
Add an extra HDMI and or DVI output to your desktop or laptop computer in minutes. Our external USB 3.0 to HDMI and DVI solution allows you to enjoy multiple monitor efficiency without opening your computer case. The USB32HDDVII USB 3.0 external video card is ideal for a wide range of applications including web browsing, multi-media presentations and video playback.
Top Buying Reasons:
External USB-to-HDMI and DVI video card solution - for use with monitors that support 1920x1200 resolutions
Connect an extra HDMI and or DVI monitor in minutes
Add workspace for office applications or simple browsing
Increase productivity with multiple monitors
Connect an HDMI and DVI-I-equipped display through a USB 3.0 port, for a 1080p HD external multi-monitor solution
1. External USB-to-HDMI and DVI video card solution - for use with monitors that support 1920x1200 resolutions
1. External USB-to-HDMI and DVI video card solution - for use with monitors that support 1920x1200 resolutions
Add extra DVI monitors to your desktop computer without having to open the computer case and risk to void manufacturer warranty
The only way to quickly expand your desktop over several monitors for laptop users
Cost effective solution to expand your computers display capabilities
2. Connect an extra HDMI and or DVI monitor in minutes
Insert the Driver CD or download the latest drivers from Startech.com, follow the on-screen instructions
While your computer re-starts connect the DVI and or HDMI cable from your secondary monitor to the USB-to-HDMI/DVI adapter
Once windows has fully re-loaded plugin the USB video adapter and follow the on-screen instructions and enjoy your new desktop real estate
2. Connect an extra HDMI and or DVI monitor in minutes
3. Add workspace for a wide range of applications including web browsing, multi-media presentations and video playback
3. Add workspace for a wide range of applications including web browsing, multi-media presentations and video playback
Ideal for word processing, spreadsheets and simple web browsing
Leave your primary display for the performance demanding applications i.e. 3D playback or games
Up to 5 displays can be added (5 USB32HDDVII adapters needed)
4. Increase productivity with multiple monitors
Multiple monitors have consistently proven to increase productivity and efficiency
Run multiple applications on different screens
Can be used on HDMI and DVI monitors and/or HDMI and DVI projectors
Compatibility
Windows 2000/ XP(32/64bit)/ Vista(32/64bit)/ 7(32/64bit)/ 8(32/64bit)
One available USB 3.0 Port
Supported Resolutions
Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x870, 1152x864, 1024x768, 832x624, 800x600, 768X567, 640X480
Widescreen(16/32 bit): 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1368x768, 1366x768, 1360x768, 1280x800, 1280x768, 1280x720, 1024x600, 848x480, 800x480, 720X480
Brand
StarTech
Model
USB32HDDVII
Type
USB to HDMI Adapters
Color
Black
Connectors
Specifications
Audio: Yes
Memory: 1GB DDR II
Industry Standards: Standard HDMI, DVI-I, SuperSpeed USB 3.0, USB 2.0
Chipset ID: DisplayLInk - DL3900
Output Signal: DVI-I (DVI Digital/Analog), HDMI
Connector A: 1 - USB 3.0 A (9 pin; SuperSpeed) Male
Connector B: 1 - DVI-I (29 pin) Female, 1 - HDMI (19 pin) Female
Maximum Digital Resolutions: 2048x1152
Supported Resolutions:
- Widescreen(16/32 bit): 2048x1152, 1920x1200, 1920x1080, 1680x1050, 1600x900, 1440x900, 1368x768, 1366x768, 1360x768, 1280x800, 1280x768, 1280x720, 1024x600, 848x480, 800x480, 720X480
- Standard(16/32 bit): 1600x1200, 1400x1050, 1280x1024, 1280x960, 1152x870, 1152x864, 1024x768, 832x624, 800x600, 768X567, 640X480
Wide Screen Supported: Yes
Audio Specifications: 5.1-Channel Surround (48Khz)
OS Compatibility: Windows 8 (32/64bit), 7 (32/64bit), Vista(32/64) (Aero 3D interface supported)
Physical Characteristics
Dimensions
6.3" X 2.9" X 2"
Weight
1.5 oz.
Features
Features
SuperSpeed USB 3.0 (5 Gbps) Interface, backward compatible with USB 2.0
Supports resolutions up to 1920x1080p (Full HD) and 2048x1152
Quick, easy installation
Dual Head design supports both HDMI and DVI-I simultaneously (DVI to VGA adapter included for VGA monitors)
USB-powered - No external power adapter required
Choose between Mirrored, Extended or Primary display configurations
Driver software supports display rotation
Supports the Windows Aero interface
Supports 5.1 channel surround sound audio (HDMI only)
Supports the use of multiple USB32HDDVII adapters on a single system (up to 3), for up to 6 additional monitors
Packaging
Package Contents
1 - USB 3.0 to HDMI/DVI-I Graphics Adapter
1 - DVI to VGA Adapter
1 - Mini USB 3.0 Cable
1 - Driver CD
1 - Installation guide
