Startech Usb Stereo Audio Adapter External Sound Card With Spdif Digital Audio Out - Usb Sound
QUICK OVERVIEW
Add an SPDIF digital audio output and standard 3.5mm audio/microphone
connections to your system through USB. The ICUSBAUDIO2D External USB Sound Card
lets you add an S/PDIF digital audio output and standard 3.5mm analog
audio/microphone connections to your system through USB - a convenient way to
bypass or replace an internal sound card without having to open the computer
case.
For home-theater quality sound, the USB DAC (digital-to-analog converter) offers
96KHz / 24-bit sampling rates for both playback and recording, and a 3.5mm
S/PDIF port with support for Dolby® Digital 5.1 surround sound (AC3) and DTS®
pass-through (Note: 5.1 surround sound is supported in Windows® only).
This versatile USB audio adapter features an integrated 3.5mm 4-position TRRS
connection for your headphones or combination headset/microphone. Also a
convenient external volume control for quick adjustments, a hardware EQ switch
for Bass or Treble boosting, and an LED status bar to display the current
sampling rate.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Product Name USB to Audio Converter External SPDIF Sound Card
Product Type External Sound Box
Channel Supported 5.1
Form Factor External
Host Interface USB 2.0
Green Compliant Yes
Green Compliance Certificate/Authority RoHS
Height 0.6"
Width 1.8"
Audio Processor VIA VT1630A
Packaged Quantity 1
Interfaces/Ports 1 x 3.5mm Mini Jack - (3 Position) Female
1 x 3.5mm Mini Jack - (4 Position) Female
1 x 3.5mm - Toslink (SPDIF; Optical) Female
Sampling Rate 24 bit 96 kHz 5.1-channel
Signal to Noise Ratio (SNR) 91 dB - (A-weighting)
Sound Channels 5.1
Thickness 1.9"
Platform Supported PC
Mac
System Requirements Operating System(s):
Windows XP (32/64 bit)
Windows Vista (32/64 bit)
Windows 7 (32/64 bit)
Windows 8 (32/64 bit)
Windows Server 2008 R2
Windows Server 2003(32/64)
Mac OS 10.x (Tested up to 10.8)
Linux
Connector(s) | |
Connector Type(s) | 3.5 mm Mini-Jack (3 Position) Female |
3.5 mm Mini-Jack (4 Position) Female | |
3.5mm Mini-Toslink (SPDIF, Optical) Female | |
USB Type-A (4 pin) USB 2.0 Male | |
Environmental | |
Humidity | 10~90% RH (Non-Condensing) |
Operating Temperature | 0?C to 60?C (32?F to 140?F) |
Storage Temperature | 0?C to 70?C (32?F to 158?F) |
Hardware | |
Bus Type | USB 2.0 |
Chipset ID | VIA/VLI - VT1630A |
Indicators | |
LED Indicators | Playback / Recording sample rate |
Power | |
Packaging Information | |
Shipping (Package) Weight | 119 g [4.2 oz] |
Performance | |
Audio Specifications | 96 KHz / 24-bit Sample Rate Approx 91dB SNR (A-weighting) 16-100ohm Headphone Drive Ability |
Physical Characteristics | |
Cable Length | 406.5 mm [16 in] |
Color | Black |
Enclosure Type | Plastic |
Product Height | 16 mm [0.6 in] |
Product Length | 47 mm [1.9 in] |
Product Weight | 40 g [1.4 oz] |
Product Width | 46 mm [1.8 in] |
Power | |
Power Source | USB-Powered |
Software | |
OS Compatibility | Windows? XP, Vista, 7, 8, 8.1, 10 Windows Server? 2003, 2008 R2, 2012, 2012 R2, 2016 Mac OS X? 10.6 to 10.8 |
Special Notes / Requirements | |
Note | 5.1 surround sound output is supported in Windows only |
System and Cable Requirements | Available USB Port |
What's in the Box | |
Included in Package | Instruction Manual |
Software CD | |
USB Stereo Audio Adapter |
The ICUSBAUDIO2D External USB Sound Card lets you add an S/PDIF digital audio output and standard 3.5mm analog audio/microphone connections to your system through USB - a convenient way to bypass or replace an internal sound card without having to open the computer case.
For home-theater quality sound, the USB DAC (digital-to-analog converter) offers 96KHz / 24-bit sampling rates for both playback and recording, and a 3.5mm S/PDIF port with support for Dolby® Digital 5.1 surround sound (AC3) and DTS® pass-through (Note: 5.1 surround sound is supported in Windows® only).
This versatile USB audio adapter features an integrated 3.5mm 4-position TRRS connection for your headphones or combination headset/microphone. Also a convenient external volume control for quick adjustments, a hardware EQ switch for Bass or Treble boosting, and an LED status bar to display the current sampling rate.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
