Startech Usb Vga Kvm Console Extender Over Cat5 Utp (500 Ft) Sv565utpu
This USB VGA KVM Console Extender lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 500ft away. PC connection cables are included with this product for a ready out of the box solution.You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.Designed to provide long lasting, reliable operation, the USB VGA Console Extender is backed by StarTech.com's 2-year warranty.
Brand Name: StarTech.com
Connectivity Technology: Wired
KVM Technology: Analog
Maximum Operating Distance: 152.40 m
Network (RJ-45): Yes
Number of Computers Supported: 2
Number of Local Users Supported: 1
Number of Remote Users Supported: 1
Product Type: KVM Console/Extender
USB: Yes
VGA: Yes
General Information
Brand Name: StarTech.com
Manufacturer Part Number: SV565UTPU
Manufacturer Website Address: http://www.startech.com
Manufacturer: StarTech.com
Marketing Information:
This USB VGA KVM Console Extender lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 500ft away. PC connection cables are included with this product for a ready out of the box solution.
You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.
Designed to provide long lasting, reliable operation, the USB VGA Console Extender is backed by StarTech.com's 2-year warranty.
Product Model: SV565UTPU
Product Name: USB VGA KVM Console Extender over CAT5 UTP - 500 ft
Product Type: KVM Console/Extender
Interfaces/Ports
Network (RJ-45): Yes
Number of Network (RJ-45) Ports: 2
Number of USB Ports: 4
Number of VGA Ports: 4
USB: Yes
VGA: Yes
Miscellaneous
Green Compliant: Yes
Power Description
Input Voltage: 110 V AC
Technical Information
Connectivity Technology: Wired
KVM Technology: Analog
Maximum Operating Distance: 152.40 m
Number of Computers Supported: 2
Number of Local Users Supported: 1
Number of Remote Users Supported: 1
Video
Graphic Mode: XGA
Maximum Video Resolution: 1024 x 768
| Connector(s) | |
| Console Interface(s) | USB Type-A (4 pin) USB 2.0 Female |
| VGA (15 pin, High Density D-Sub) Female | |
| Host Connectors | VGA (15 pin, High Density D-Sub) Female |
| Other Interface(s) | RJ-45 Female |
| Environmental | |
| Humidity | 0~80% RH |
| Operating Temperature | 0?C to 40?C (32?F to 104?F) |
| Storage Temperature | -20?C to 60?C (-4?F to 140?F) |
| Hardware | |
| Audio | No |
| KVM Ports | 2 |
| Number of Monitors Supported | 1 |
| PC Interface | USB |
| PC Video Type | VGA |
| Rack-Mountable | No |
| Packaging Information | |
| Shipping (Package) Weight | 1.7 kg [3.8 lb] |
| Performance | |
| IP Control | No |
| Max Transfer Distance | 150 m (492 ft) |
| Supported Resolutions | 1280 x 1024 @ 300ft/ 100m 1024 x 768 @ maximum cable length |
| Physical Characteristics | |
| Color | Black |
| Product Height | 20 mm [0.8 in] |
| Product Length | 75 mm [3 in] |
| Product Weight | 299 g [10.6 oz] |
| Product Width | 155 mm [6.1 in] |
| Power | |
| Center Tip Polarity | Positive |
| Input Current | 0.2A |
| Input Voltage | 110V-240V AC |
| Output Current | 0.6A |
| Output Voltage | 9 DC |
| Plug Type | M |
| Power Consumption (In Watts) | 5.4 |
| Power Source | AC Adapter Included |
| Software | |
| OS Compatibility | OS independent; No software or drivers required |
| Special Notes / Requirements | |
| Note | Product weights/measurements and connector types indicate a single unit only (either Host or Remote) |
| What's in the Box | |
| Included in Package | 6 ft 2-in-1 USB VGA KVM cables |
| host unit | |
| instruction manual | |
| power adapter | |
| remote unit | |
| rubber feet | |
The SV565UTPU USB VGA KVM Console Extender over CAT5 UTP (500 ft) lets you control a server, computer or multiple computers (connected through KVM Switch) over a standard Cat5 or Cat6 UTP network cable connection, at distances of up to 500 ft (150 m) away. PC connection cables are included with this product for a ready out of the box solution.
You can use your existing keyboard, mouse, and monitor to access both the server room and your office computer, saving space and avoiding the need for a dedicated remote console by allowing you to switch between workstation view and KVM view at the remote location.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
