Tenda (Teg1110Pf-8-102W) Port Gigabit Desktop Switch With 8-Port PoE+ TEG1110PF-8-102W
SKU
397510
Brand
MPN
TEG1110PF-8-102W
Warranty
Standard Manufacturer's Warranty
$177.00
Buy Now And Earn 177 Reward Points!
Tenda TEG1110PF-8-102W -Port Gigabit Desktop Switch with 8-Port PoE+
| SKU | TEG1110PF-8-102W |
|---|---|
| Brand | Tenda |
| Model | TEG1110PF-8-102W |
| Cooling | Fanless (silent design) |
| Category | Networking |
| Description | The Tenda TEG1110PF-8-102W is an unmanaged 10-port gigabit Ethernet PoE switch designed for small-to-medium surveillance and wireless deployments. It provides 8 PoE-enabled RJ45 ports plus one RJ45 uplink and one SFP uplink, supports IEEE 802.3af/at, and delivers a total PoE budget of 102 W (up to 30 W per port). With a 20 Gbps switching capacity, 14.9 Mpps forwarding rate, three operating modes (Standard, VLAN and Extend — Extend extends copper transmission up to 250 m), smart PoE power management and 6 kV lightning protection, this compact fanless switch is optimized for HD IP camera systems, access points and other PoE devices. |
| Power Input | AC 100-240 V, 50/60 Hz |
| Switch Type | Unmanaged PoE Switch |
| Total Ports | 10 (8 PoE RJ45 + 1 RJ45 + 1 SFP) |
| PoE Features | Smart PoE power management (auto power-off of low-priority ports when budget exceeded); supports up to 8 powered devices |
| Sub-Category | Switches and Hubs |
| Datasheet URL | https://www.tendacn.com/download/detail-4388.html |
| Key Use Cases | HD video surveillance, gigabit wireless networking (APs), VoIP phones, small/medium enterprises, hotels, schools, industrial parks |
| Packet Buffer | 2 MB |
| PoE Standards | IEEE 802.3af, IEEE 802.3at |
| Product Title | Tenda TEG1110PF-8-102W 9GE+1SFP Unmanaged Gigabit PoE Switch (8-Port PoE, 102W) |
| Certifications | CE, FCC, RoHS |
| LED Indicators | Link/activity LEDs for ports (10) and 1 Power LED |
| SFP Port Speed | 100/1000 Mbps SFP |
| Forwarding Mode | Store-and-forward |
| Forwarding Rate | Approx. 14.9 Mpps (14.88 Mpps listed in some specs) |
| Operating Modes | Standard (default, full connectivity), VLAN (ports 1-8 isolated from each other but can reach port 9 and SFP), Extend (ports 1-8 extended up to 250 m) |
| Max PoE Per Port | 30 W (802.3at); 15.4 W (802.3af) |
| RJ45 Port Speeds | 8 x 10/100/1000 Mbps (PoE), 1 x 10/100/1000 Mbps (uplink) |
| Storage Humidity | 5% to 90% non-condensing |
| Total PoE Budget | 102 W |
| MAC Address Table | 16K entries |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at |
| What's in the Box | Tenda TEG1110PF-8-102W switch, power adapter (51V/2A), quick installation guide |
| Operating Humidity | 10% to 90% non-condensing |
| Port Configuration | 8 x PoE RJ45 ports (Data + Power), 1 x RJ45 uplink (Data), 1 x SFP uplink (fiber) |
| Switching Capacity | 20 Gbps (non-blocking) |
| Jumbo Frame Support | Up to 9,216 bytes |
| Storage Temperature | -40°C to 70°C |
| Power Adapter Output | 51 V DC, 2.0 A (external power adapter) |
| Protection and Surge | 6 kV lightning protection (ports and power); ESD: air ±10 kV, contact ±8 kV (per datasheet listings) |
| Operating Temperature | 0°C to 45°C (per manufacturer datasheet listings) |
| Form Factor / Mounting | Desktop and wall-mount supported (rack-mount not supported) |
| Physical Dimensions (L×W×H) | 177.5 mm x 104.0 mm x 26.0 mm |
TENDA (TEG1110PF-8-102W) Port Gigabit Desktop Switch with 8-Port PoE+
