TP-Link JetStreamâ„¢ 16-Port Gigabit Smart Switch With 8-Port PoE+ -(Tl-Sg2016P) SG2016P
SKU
396532
Brand
MPN
SG2016P
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$330.00
Buy Now And Earn 330 Reward Points!
TP-Link JetStreamâ„¢ 16-Port Gigabit Smart Switch with 8-Port PoE+
PORT: 8× Gigabit PoE+ Ports
SPEC: 802.3af/at, 120 W PoE Power, Desktop Steel Case
FEATURE: Integration with Omada SDN Controller, Static Routing, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image, IPv6"
PORT: 8× Gigabit PoE+ Ports
SPEC: 802.3af/at, 120 W PoE Power, Desktop Steel Case
FEATURE: Integration with Omada SDN Controller, Static Routing, 802.1Q VLAN, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image, IPv6"
| QoS | 802.1p CoS / DSCP 8 priority queues Strict Priority (SP) and WRR Rate limit / Bandwidth control Traffic classification and prioritization |
|---|---|
| SKU | SG2016P |
| UPC | 840030709494 |
| ASIN | B0BS1NWTGN |
| VLAN | 802.1Q tag VLAN Up to 4K VLAN groups MAC VLAN Protocol VLAN GVRP Voice VLAN |
| Brand | TP-Link |
| Color | Black |
| Model | TL-SG2016P |
| Series | SG2016P / JetStream / Omada |
| Weight | 0.93 kg (2.05 lb) |
| Warranty | 5-year manufacturer warranty |
| Data Rate | 1000 Mbps |
| Multicast | IGMP snooping v1/v2/v3 IGMP Snooping Querier MLD snooping v1/v2 Multicast VLAN Registration (MVR) |
| PoE Ports | 8 |
| Port Type | RJ45 (Ports 1–8 support 802.3at/af PoE+) |
| Interfaces | 16 × 10/100/1000 Mbps RJ45 ports (ports 1–8 PoE+), Auto-Negotiation/Auto MDI/MDIX |
| Management | Smart Managed |
| Port Speed | 10/100/1000 Mbps (Gigabit) |
| Description | TP-Link TL-SG2016P (SG2016P) is a 16-port Gigabit smart switch with eight 802.3af/at PoE+ ports and a 120 W total PoE budget. Designed for small and mid-sized business networks, it provides full Gigabit connectivity (8 PoE+ ports + 8 non-PoE ports), fanless silent operation, Omada SDN integration for centralized cloud management (Omada Cloud/OC200/OC300/Software Controller), Zero-Touch Provisioning, and comprehensive L2/L2+ and L3-lite features including static routing, VLAN, ACL, QoS, IGMP snooping and link aggregation. Security features include IP-MAC-Port binding, 802.1X/RADIUS, DHCP snooping, ARP inspection, DoS defense and port security. Compact desktop or wall-mountable form factor; includes power adapter, installation guide and rubber feet. |
| Environment | Storage Humidity: 5–90% RH non-condensing Operating Humidity: 10–90% RH non-condensing Storage Temperature: -40–70 °C (-40–158 °F) Operating Temperature: 0–40 °C (32–104 °F) |
| Part Number | TL-SG2016P |
| Performance | Jumbo Frame: 9 KB MAC Address Table: 8K entries Packet Buffer Memory: 4.1 Mbit Backplane / Switching Capacity: 16 Gbps |
| PoE Standard | IEEE 802.3af IEEE 802.3at |
| Auto MDI/MDIX | Yes |
| Product Title | TP-Link Omada JetStream TL-SG2016P — 16-Port Gigabit Smart Switch with 8-Port PoE+ (120W) |
| Certifications | CE FCC RoHS |
| Layer Features | L2 switching L2+ / L3-lite features Static Routing Link Aggregation (Static & 802.3ad LACP) STP/RSTP/MSTP |
| Number of Ports | 16 |
| Hardware Version | V1.20 |
| Hardware Features | Fanless: true Form Factor: Desktop / Wall-mountable; standalone Power Supply: External power adapter (Output: 53.5 V DC, 2.43 A) Max Heat Dissipation: 499.98 BTU/hr (with 120 W PD connected) Max Power Consumption: 146.5 W (with 120 W PD connected) |
| SDN Compatibility | Omada SDN (supports Omada controllers and app; SDN firmware required for SDN controllers) |
| Security Features | IP-MAC-Port Binding Access Control List (ACL) Port Security (static/dynamic/permanent) 802.1X (including MAB, Radius authentication) DHCP Snooping / DHCPv6 Snooping ARP Inspection / ND Detection IP/IPv6 Source Guard DoS Defense Storm Control Port Isolation Secure management (HTTPS, SSH) |
| Compatible Devices | IP cameras Wireless access points (Omada EAPs) IP phones / VoIP phones Computers / PCs Printers Servers Network Attached Storage (NAS) Other network switches |
| PoE Budget (Total) | 120 W |
| PoE per Port (max) | Up to 30 W per PoE+ port |
| Included Components | TL-SG2016P switch (unit) Power adapter Installation guide Rubber feet |
| Management Features | Omada Cloud-Based Controller Omada Hardware Controller (OC200/OC300) Omada Software Controller Omada Mobile App Web-based GUI Command Line Interface (CLI) via Telnet/SSH SNMP v1/v2c/v3 RMON Batch configuration and firmware upgrade Zero-Touch Provisioning Cable diagnostics Dual image/dual configuration |
| System Requirements | Management tools compatible with Windows, macOS, Linux; Omada Controller runs on supported platforms (see TP-Link documentation) |
| Standards & Protocols | IEEE 802.3i IEEE 802.3ab IEEE 802.3ad IEEE 802.3af IEEE 802.3at IEEE 802.3x IEEE 802.1d IEEE 802.1s IEEE 802.1w IEEE 802.1q IEEE 802.1p IEEE 802.1x |
| Dimensions (W x D x H) | 11.3 x 4.4 x 1.0 in (286 x 111.7 x 25.4 mm) |
TP-Link JetStreamâ„¢ 16-Port Gigabit Smart Switch with 8-Port PoE+ -(TL-SG2016P)
