TP-Link 24-Port 10/100Mbps PoE+ Switch, 24 10/100Mbps RJ45 Ports, 2 Gigabit RJ45 Ports, 2 Combo Sfp Slots, 3-Year Wty TL-SL1226P
SKU
392411
Brand
MPN
TL-SL1226P
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$349.00
Buy Now And Earn 349 Reward Points!
TP-Link 24-Port 10/100Mbps PoE+ Switch, 24 10/100Mbps RJ45 Ports, 2 Gigabit RJ45 Ports, 2 Combo SFP Slots, 802.3at/af, 250W PoE Power, 1U 19-inch Rack-mountable Steel Case, Extend Mode for 250m PoE Transmitting, Priority Mode for Port1-8, Isolation Mode
| SKU | TL-SL1226P |
|---|---|
| UPC | 845973089443 |
| Fans | 2 |
| Brand | TP-Link |
| Color | Black |
| Model | TL-SL1226P |
| Notes | Extend Mode increases PoE/data range to 250 m but port speed is downgraded to 10 Mbps. PoE budget figures are based on laboratory testing and actual available power may vary based on connected devices and environment. |
| Ports | 24 × 10/100 Mbps PoE+ RJ45 (ports 1–24) |
| Weight | 6.4 lb (2.9 kg) (listed product weight) |
| Category | Networking |
| Material | Metal |
| Warranty | 3-Year Limited Warranty |
| SFP Slots | 2 × Combo Gigabit SFP (shared with RJ45 uplinks) |
| Description | The TP-Link TL-SL1226P is an unmanaged Layer 2 PoE+ switch designed for surveillance, offices and small business networks. It provides 24× 10/100 Mbps PoE+ RJ45 ports (802.3af/at), 2× Gigabit RJ45 uplink ports and 2× combo Gigabit SFP slots (shared). The switch offers a 250 W total PoE power budget (up to 30 W per port), Extend Mode for PoE/data up to 250 m (port speed downgraded to 10 Mbps in Extend Mode), Priority Mode (ports 1–8) and Isolation Mode for traffic separation. Plug-and-play with intelligent power management to prevent overload, the TL-SL1226P supports auto MDI/MDIX, IEEE802.3x flow control, MAC auto-learning/aging and store-and-forward switching. Durable metal casing, rack-mount/desktop form factor and professional heat dissipation enable reliable operation in 0–50 °C environments. |
| Jumbo Frame | 10 KB |
| Power Input | AC 100–240 V, 50/60 Hz |
| Flow Control | IEEE 802.3x |
| Manufacturer | TP-LINK Technologies Co., Ltd |
| PoE Standard | IEEE 802.3af/802.3at (PoE/PoE+) |
| Sub-Category | Switches and Hubs |
| Uplink Ports | 2 × Gigabit RJ45 (10/100/1000) (uplink) |
| Auto Features | Auto MDI/MDIX, Auto-negotiation, MAC auto-learning and auto-aging |
| Priority Mode | Ports 1–8 (one-touch) |
| Product Title | TP-Link TL-SL1226P 24-Port 10/100Mbps PoE+ Unmanaged Switch (24 PoE+, 2 Gigabit RJ45 + 2 Combo SFP, 250W) |
| Certifications | FCC |
| Isolation Mode | Ports 1–24 (one-click traffic separation) |
| Layer Supported | Layer 2 |
| Management Type | Unmanaged |
| PoE Ports Count | 24 |
| Package Contents | TL-SL1226P switch Power cable Installation guide Two mounting brackets and fittings |
| PoE Per Port Max | Up to 30 W per port |
| PoE Power Budget | 250 W (total) |
| Storage Humidity | 5–90% non-condensing |
| Country of Origin | China |
| Extend Mode Range | Up to 250 m (speed downgraded to 10 Mbps) |
| MAC Address Table | 8 K |
| Network Technology | 10/100Base-T, 1000Base-T, 1000Base-X |
| Operating Humidity | 10–90% non-condensing |
| Switching Capacity | 8.8 Gbps |
| Ethernet Technology | Fast Ethernet (10/100), Gigabit Ethernet (1000Base-T/1000Base-X) |
| Storage Temperature | -40–70 °C (-40–158 °F) |
| TAA/NDAA Compliance | Not TAA / NDAA compliant (listed as No) |
| Total Network Ports | 26 |
| Transmission Method | Store-and-forward |
| Max Heat Dissipation | 62.47 BTU/h (no PD); 1002.54 BTU/h (with 250 W PD) |
| Operating Temperature | 0–50 °C (32–122 °F) |
| Dimensions (W x D x H) | 440 × 180 × 44 mm (17.3 × 7.1 × 1.7 in) |
| Packet Forwarding Rate | 6.5472 Mpps |
| Physical Security Lock | Yes |
| Power Consumption (No PD) | 18.32 W (220 V/50 Hz, no PD connected) |
| Intelligent Power Management | Yes (auto cuts lower-priority ports when total consumption exceeds budget) |
| Max Power Consumption (With PD Connected) | 294 W (220 V/50 Hz, with 250 W PD connected) |
