Tp-link Tl-wr802n Wireless N Mini Pocket Ap Router 10/ 100(1) 300mbps 802.11n/ G/ B Tl-wr802n

SKU
246537
Brand
Tp-link
Manufacturer Link
MPN
TL-WR802N
Manufacturer Product Link
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
$43.00
Buy Now And Earn 43 Reward Points!
Add to Compare


Multiple Operating Modes

Ideal for Home and Travel Use

To meet the wireless needs of almost any situation you might encounter, the TL-WR802N supports Router, Hotspot, Range Extender, Client and Access Point Modes.

During Travel

Router Mode

Instantly create a private wireless network and share Internet access with multiple Wi-Fi devices. Ideal for setup in most hotels.

*Travel Streaming with Chromecast and Amazon Fire TV Stick Instantly Share Internet Connection during Travel.

Hotspot Mode

Enjoy wireless Internet access by connecting to an outdoor WISP Access Point.

At Home

Range Extender Mode

Extend existing Wi-Fi to improve signal strength and maximize coverage.

Client Mode

Allow devices that require a wired connection to access an existing Wi-Fi network.

Access Point Mode

Create a wireless network for Wi-Fi devices.

Portable and Compact - Suitable for Home and Travel

The TL-WR802N is the smallest wireless router in the world. It is very easy to use and is a perfect choice for travelers, students, and anyone else who lives life on the go.

Flexible Power Supply - Find Power Wherever You Are

The TL-WR802N can be powered using the included power adapter or using a smartphone /USB charger.

  • Powered by
    Power Adapter
  • Powered by Smartphone Charger
  • Powered by USB Port
HARDWARE FEATURES
Interface 1 10/100Mbps WAN/LAN Port
1 Micro USB Port
1 Reset Button
External Power Supply 5V/1A
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 2.2 x 2.2 x 0.7 in. (57 x 57 x18 mm)
Antenna Type On-Board
WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 270M: -65dBm@10% PER
130M: -70dBm@10% PER
108M: -82dBm@10% PER
54M: -73dBm@10% PER
11M: -82dBm@8% PER
6M: -86dBm@10% PER
1M: -90dBm@8% PER
Transmit Power CE:
<20dBm(2.4GHz)
FCC:
<30dBm
Wireless Modes Router Mode, Repeater Mode, Client Mode, AP Mode, WISP Router Mode
Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless Statistics
Wireless Security 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control
WAN Type Dynamic IP/Static IP/PPPoE/
PPTP/L2TP
Management Access Control
Local Management
Remote Management
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Access Control Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
OTHERS
Certification CE, FCC, RoHS
Package Contents TL-WR802N
Power Adapter
USB Cable
Ethernet cable
Quick Installation Guide
Resource CD
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 10/8.1/8/7
MAC®OS, NetWare®, UNIX® or Linux
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
