Qnap Ts-453E-8G, 4-bay Desktop Nas, Intel Celeron J6412 4C 2.0GHz, Burst 2.6GHz, Onboard 8GB Ram, 2 X Hdmi 1.4b, 2x M.2 2280 PCIe Slots, 2x 2.5GbE, 2 Years Wty TS-453E-8G
SKU
387787
Brand
MPN
TS-453E-8G
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,594.00
Buy Now And Earn 1594 Reward Points!
QNAP TS-453E-8G, 4-bay desktop NAS, Intel Celeron J6412 4C 2.0GHz, burst 2.6GHz, onboard 8GB RAM, 2 x HDMI 1.4b, 2x M.2 2280 PCIe slots, 2x 2.5GbE, 2 Years WT
| SKU | TS-453E-8G |
|---|---|
| Brand | QNAP |
| Color | Black |
| Model | TS-453E-8G |
| Notes | Some vendor listings append region-specific model suffixes (e.g., -US). The consolidated model is TS-453E-8G. Manufacturer materials reference long-term availability and suitability for deployments requiring model continuity. Do not include hard drives; many retail listings are diskless by default (unit sold as enclosure). |
| Power | External AC adapter; power provided listed as 90 W (adapter); operational power consumption reported ~33.88 W |
| Weight | 6.61 lbs |
| Voltage | AC 100–240 V (external power adapter) |
| Features | Dual 2.5GbE for accelerated file sharing and link aggregation Dual M.2 NVMe slots for SSD caching or storage pools Dual HDMI outputs for direct multimedia playback and surveillance monitoring Hardware-accelerated encryption and media transcoding Long-term availability / platform continuity (manufacturer commitment) Comprehensive NAS services: snapshot, backup, virtualization, multimedia streaming, surveillance (QVR), iSCSI, cloud sync and more |
| Warranty | Limited 3-year warranty (extendable up to 5 years) |
| CPU Cores | Quad-core (4 cores / 4 threads) |
| M.2 Slots | 2 x M.2 2280 NVMe (PCIe Gen3 x2) for SSD caching or storage pools |
| Processor | Intel Celeron J6412 |
| USB Ports | 2 x USB 3.2 Gen 2 (10 Gb/s), 2 x USB 2.0 |
| Drive Bays | 4 hot-swappable bays (supports 2.5" and 3.5" HDD/SSD) |
| Description | The QNAP TS-453E-8G is a compact, high-performance 4-bay desktop NAS powered by an Intel Celeron J6412 quad-core processor and onboard 8 GB DDR4 memory. Designed for home, small office and edge deployments, it delivers fast file sharing with dual 2.5GbE ports, supports SSD caching via two M.2 2280 PCIe NVMe slots, and offers direct multimedia output and surveillance monitoring via dual HDMI (up to 4K @30Hz). The unit includes AES-NI encryption and hardware-accelerated media decoding/transcoding, supports QNAP QTS and QuTS hero operating systems, and is backed by a standard 3-year warranty (extendable up to 5 years). |
| HDMI Outputs | 2 x HDMI, supports up to 4K (3840 x 2160) @30Hz |
| Memory (RAM) | 8 GB onboard DDR4 (non-upgradable/onboard) |
| Product Title | QNAP TS-453E-8G 4-Bay NAS (Intel Celeron J6412, 8GB DDR4, Dual 2.5GbE, Dual M.2 NVMe, Dual HDMI) |
| Network Interfaces | 2 x 2.5GbE RJ-45 ports (supports 2.5G/1G/100M) |
| Supported Protocols | SMB/CIFS, AFP, NFS v3/v4, FTP, SFTP, HTTP/HTTPS, iSCSI, WebDAV, etc. |
| Included Accessories | TS-453E-8G unit Ethernet cable x1 Power cord / AC adapter Drive tray keys x2 Flat head screws for M.2 SSD x2 Flat head screws for 3.5" HDD x16 Flat head screws for 2.5" HDD x12 Quick installation guide |
| Encryption & Security | AES-NI; 256-bit AES support; FIPS 140-2 (listed); SSL/TLS support (TLS 1.0–1.3 mentioned); Kensington security slot |
| RAID Levels Supported | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| Supported Drive Types | 3.5" SATA, 2.5" SATA |
| Dimensions (H x W x D) | 6.7 x 7.1 x 9.3 inches |
| Flash Memory Installed | 4 GB (as reported by manufacturer listing) |
| Performance (Measured) | SMB Sequential Throughput (2.5GbE x2): Write 578.24 MB/s, Read 578.24 MB/s; iSCSI Random 4K IOPS (2.5GbE x2): Write 132,886 IOPS, Read 140,837 IOPS |
| CPU Max Turbo Frequency | Burst up to 2.6 GHz |
| Hardware Acceleration / AI | Intel AES-NI encryption engine; Intel OpenVINO support (AI engine); hardware decoding and real-time transcoding; Edge TPU supported (optional) |
| Built-in Devices / Hardware | LED panel 120mm cooling fan Kensington security slot |
| Minimum Memory Requirements | 2 GB available; 4 GB installed (minimum requirement note) |
| Operating System / Software | QNAP QTS (version listed: QTS 5.0.1 on some listings); QuTS hero (ZFS-based) supported |
| Storage Controller Interface | Serial ATA (SATA III / SATA-600) |
QNAP TS-453E-8G, 4-bay desktop NAS, Intel Celeron J6412 4C 2.0GHz, burst 2.6GHz, onboard 8GB RAM, 2 x HDMI 1.4b, 2x M.2 2280 PCIe slots, 2x 2.5GbE, 2 Years WTY
