QNAP 4-BAY NAS 3.5"(0/4), ATOM X7405C-3.4GHz, 8GB, 2.5GbE(2), M.2/E1.S(3), 1U RACK, 3YR WT TS-H765EU-8G
SKU
434082
Brand
MPN
TS-H765EU-8G
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$1,779.00
Buy Now And Earn 1779 Reward Points!
The 1U short-depth rackmount TS-G765eU is designed for space-constrained environments, offering an efficient and reliable storage solution for various needs. Adopting the latest Intel® Atom x7000C Series processor, the TS-h765eU comes with four 3.5-inch drive bays and three E1.S / M.2 PCIe NVMe slots for exceptional expandability, making it an ideal NAS for high performance and multitasking demands. The TS-h765eU runs the ZFS-based QuTS hero operating system that ensures data integrity and WORM protection for data immutability.
| CPU | Intel Atom x7405C, 4-core, up to 3.4GHz |
| CPU Architecture | 64-bit x86 |
| Floating Point Unit | Yes |
| Encryption Engine | Yes (AES-NI) |
| System Memory | 8 GB SODIMM DDR5 (1 x 8 GB), enabled in-band ECC |
| Maximum Memory | 16 GB (1 x 16 GB) |
| Memory Slot | 1 x SODIMM DDR5 |
| Flash Memory | 8GB (Dual boot OS protection) |
| Drive Bay | 4 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| 3 x E1 S up to 15mm (Pre-installed adapter for M 2 2280) | 3 x E1.S up to 15mm (Pre-installed adapter for M.2 2280) |
| Drive Compatibility | - 3.5-inch SATA hard disk drives |
| - 2 5-inch SATA solid-state drives | - 2.5-inch SATA solid-state drives |
| - E1 S NVMe PCIe SSDs | - E1.S NVMe PCIe SSDs |
| - M 2 2280 NVMe PCIe SSDs | - M.2 2280 NVMe PCIe SSDs |
| Hot-swappable | Yes |
| M 2 Slot | 3 x E1.S up to 15mm (Pre-installed adapter for M.2 2280) |
| SSD Cache Acceleration Support | Yes |
| GPU Pass-through | Yes |
| 2 5 Gigabit Ethernet Port | 2 (2.5G/1G/100M/10M) |
| 10 Gigabit Ethernet Port | Optional via a PCIe adapter |
| Wake on LAN (WOL) | Yes |
| Jumbo Frame | Yes |
| USB 2 0 Port | 1 |
| USB 3 2 Gen 1 Port | 1 |
| Form Factor | 1U Short Depth Rackmount |
| LED Indicators | Power/Status, LAN, USB, HDD1-4, E1.S/PCIe SSD1~3 |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 43 × 430 × 292.1 mm |
| Weight (Net) | 4.51 kg |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 150W, 100-240V |
| Fan | 3 x 40mm |
| System Warning | Buzzer |
| Standard Warranty | 3 years |
| Max Number of Concurrent Connections (CIFS) - with Max Memory | 1500 |
QNAP 4-BAY NAS 3.5"(0/4), ATOM X7405C-3.4GHz, 8GB, 2.5GbE(2), M.2/E1.S(3), 1U RACK, 3YR WT
