QNAP TS-h987XU-RP-E2334-16G, 9-Bay 1U rackmount NAS, Intel Xeon E-2334 4 cores / 8 threads 3.4 GHz processor (boost up to 4.8 GHz), 16 GB ECC DDR4, 3 Yrs WTY TS-h987XU-RP-E2334-16G
SKU
406014
Brand
MPN
TS-h987XU-RP-E2334-16G
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Special Price $5,380.00 Regular Price $6,187.00
Buy Now And Earn 5380 Reward Points!
| CPU | Intel® Xeon® E-2334 4C 8T 3.4GHz, up to 4.8GHz |
| CPU Architecture | 64-bit x86 |
| Floating Point Unit | |
| Encryption Engine | (AES-NI) |
| System Memory | 16 GB ECC DDR4 (1 x 16 GB) |
| Maximum Memory | 128GB (4 x 32 GB) |
| Memory Slot | 4 x ECC UDIMM DDR4
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
|
| Flash Memory | 5GB (Dual boot OS protection) |
| Drive Bay | 9 (4 x 3.5-inch SATA + 5 x 2.5-inch U.2 PCIe / SATA)
2.5-inch bays:
#1: PCIe Gen3 x2 & SATA 6Gbps #2: PCIe Gen3 x2 & SATA 6Gbps #3: PCIe Gen3 x2 & SATA 6Gbps #4: PCIe Gen4 x4 & SATA 6Gbps #5: PCIe Gen4 x4 & SATA 6Gbps |
| Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives 2.5-inch bays: 2.5-inch U.2/U.3 NVMe PCIe solid state drives 2.5-inch SATA solid state drives The 2.5-inch bay only support maximum 7mm height drives. |
| Hot-swappable | |
| M.2 Slot | Optional via a QM2 PCIe adapter
Compatible with NVMe SSD PCIe Gen 3 and above. Please refer to https://www.qnap.com/compatibility/ for compatibility.
|
| SSD Cache Acceleration Support | |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 2 (2.5G/1G/100M) |
| 10 Gigabit Ethernet Port | 2 x 10GBASE-T (10G/5G/2.5G/1G/100M) |
| 25 Gigabit Ethernet Port | Optional via a PCIe adapter |
| Wake on LAN (WOL) | |
| PCIe Slot | 1 x Gen4 x8
Card dimensions for PCIe slot：215 x 68.9x 18.76 mm / 8.46 x 2.71 x 0.74 inches
|
| USB 3.2 Gen 2 (10Gbps) Port | 4 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
| Form Factor | 1U Rackmount |
| LED Indicators | Status (Green/Red) LAN (Green) HDD status (Green/Red) |
| Buttons | Power, Reset |
| Dimensions (HxWxD) | 1.7 × 16.93 × 18.86 inch |
| Weight (Net) | 18.58 lbs |
| Weight (Gross) | 24.54 lbs |
| Operating Temperature | 0 - 40 °C (32°F - 104°F) |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Relative Humidity | 5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit | 2 x 300W PSU |
| Power Consumption: HDD Sleep Mode | 114.6 W |
| Power Consumption: Operating Mode, Typical | 120.58 W |
| Fan | 4 x 40mm, 12VDC |
| Standard Warranty | 3 |
| Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 11000 |
