Qnap TS-i410X-8G,4-bay Desktop Nas; Intel Atom X6425E Quad-core, Onboard 8GB RAM (not Expandable), 4 X 2.5-inch Sata Slots, 2 X 10GbE, 1 X Hdmi 1.4b, 3 Yrs Wty TS-i410X-8G
SKU
404789
Brand
MPN
TS-i410X-8G
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$2,586.00
Buy Now And Earn 2586 Reward Points!
QNAP TS-i410X-8G, 4-bay Desktop NAS; Intel Atom x6425E quad-core, onboard 8GB RAM (not expandable), 4 x 2.5-inch SATA slots, 2 x 10GbE, 1 x HDMI 1.4b, 4 x USB 3.2 Gen2 Type-A, wide temp(-40°C to 70°C), input voltage tolerance(DC 9-36V)
| EAN | 0885022023813 |
|---|---|
| MPN | TS-I410X-8G |
| SKU | TS-i410X-8G |
| UPC | 885022023813 |
| ASIN | B0B8LW6R9L |
| HDMI | 1 x HDMI 1.4b (up to 3840 x 2160 @ 30Hz) |
| Brand | QNAP |
| Model | TS-i410X-8G |
| Notes | System is shipped without HDDs. Some RAM reserved for shared graphics memory. |
| Buttons | Power, Reset |
| Category | Storage |
| Diskless | Yes |
| Graphics | Intel UHD Graphics (integrated) |
| Processor | Intel Atom x6425E |
| USB Ports | 4 x USB 3.2 Gen 2 Type-A (10 Gbps) |
| Drive Bays | 4 x 2.5-inch SATA (6Gb/s, 3Gb/s) |
| Description | The QNAP TS-i410X-8G is a rugged, fanless 4-bay industrial NAS optimized for harsh environments and edge deployments. Powered by an Intel Atom x6425E quad-core processor (burst up to 3.0 GHz) with Intel UHD graphics and 8 GB DDR4 onboard memory (non-expandable), it delivers high-speed file sharing, backup, virtualization and edge-computing capabilities. The system provides dual 10GBASE-T/NBASE-T RJ45 ports (10G/5G/2.5G/1G/100M), four USB 3.2 Gen 2 Type-A ports, and an HDMI 1.4b output (up to 4K@30Hz). Designed for industrial use, the TS-i410X operates across a wide temperature range (-40 to 70°C), supports 9–36V DC wide-range power input (and external AC adapter), and meets rugged deployment needs (MIL-STD-810H noted). AES-NI hardware encryption, support for 4 x 2.5" SATA 6Gb/s drives (diskless), RAID levels 0/1/5/6/10/JBOD/Single, QTS 5 operating system, and SSD caching options make it suitable for demanding IOPS and throughput requirements. |
| Form Factor | 4-bay fanless industrial NAS (tower / rugged) |
| Flash Memory | 4 GB (dual-boot OS protection) |
| Power Supply | External power adapter (90W and above) AC 100–240V; supports DC 9–36V wide-range input |
| Sub-Category | Network Attached Storage (NAS) |
| Weight (Net) | 5.6 lbs (approx. 2.54 kg) |
| Network Ports | 2 x 10GBASE-T/NBASE-T RJ45 (supports 10G/5G/2.5G/1G/100M) |
| Product Title | QNAP TS-i410X-8G 4-Bay Fanless Industrial NAS — Intel Atom x6425E, 8GB DDR4, Dual 10GBASE-T, HDMI 1.4b (Diskless) |
| System Memory | 8 GB DDR4 onboard (non-expandable) |
| LED Indicators | Power/Status, LAN, SSD 1-4 |
| Maximum Memory | 8 GB (onboard) |
| Operating System | QTS 5 |
| Encryption Engine | Hardware-accelerated AES-NI |
| Hardware Features | Fanless industrial design, MIL-STD-810H (noted), wide-temperature operation, vibration/dust-tolerant chassis |
| Processor Details | Quad-core (4C/4T), burst up to 3.0 GHz; 64-bit x86 architecture |
| Relative Humidity | 5–95% RH non-condensing (wet bulb: 27°C / 80.6°F) |
| Drive Compatibility | 2.5-inch SATA SSDs/HDDs (system shipped diskless) |
| Storage Temperature | -45 to 85 °C (-49 to 185 °F) |
| Included Accessories | 10GBASE-T Ethernet cable x1, Power cord x1, AC adapter PWR-ADAPTER-96W-A02, 16 x flat head screws (for 2.5" drives), Quick Installation Guide |
| Operating Temperature | -40 to 70 °C (-40 to 158 °F) |
| Supported RAID Levels | RAID 0, 1, 5, 6, 10, JBOD, Single |
| Dimensions (H x W x D) | 2.56 × 7.09 × 10 inch |
| Additional Network Notes | NBASE-T support for lower link speeds (5G/2.5G/1G/100M) |
| Product Dimensions (L x W x H) | 10 × 7.09 × 2.5 inches |
| Supported Protocols / Features | iSCSI support, SSD cache acceleration support, 4K media playback and real-time transcoding (HDMI) |
| Maximum Concurrent Connections (with max memory) | 1500 (as specified) |
QNAP TS-i410X-8G,4-bay Desktop NAS; Intel Atom x6425E quad-core, onboard 8GB RAM (not expandable), 4 x 2.5-inch SATA slots, 2 x 10GbE, 1 x HDMI 1.4b, 3 yrs WTY
