Qnap TVS-h674-i5-32G,6-bay QuTS Hero Nas, Intel Core I5-12400 6-core/12-thread, Up To 4.6GHz, 32GB So-Dimm DDR4(max.128GB), 6 X 2.5"/3.5" Sata Hdd/SSD, 3 Yrs TVS-h674-i5-32G
SKU
395377
Brand
MPN
TVS-h674-i5-32G
Warranty
Standard Manufacturer's Warranty
Availability
In stock
$5,732.00
Buy Now And Earn 5732 Reward Points!
QNAP TVS-h674-i5-32G, 6-bay QuTS hero NAS, Intel® Core™ i5-12400 6-core/12-thread, up to 4.6GHz, 32GB SO-DIMM DDR4(max.128GB), 6 x 2.5"/3.5" SATA HDD/SSD, 2 x 2.5GbE, 2x M.2 PCIe Gen4 x4 slots, PCIe Gen4 slots, HDMI 1.4b, 250W PSU
| CPU | Intel Core i5-12400 (6 cores / 12 threads, up to 4.4 GHz) |
|---|---|
| GPU | Intel UHD Graphics 730 |
| SKU | TVS-h674-i5-32G |
| Brand | QNAP |
| Color | Black |
| Model | TVS-h674-i5-32G |
| Buttons | Power, Reset, USB Copy |
| Cooling | System fans: 2 x 92 mm; CPU fan: 1 x 60 mm |
| M.2 Slots | 2 x M.2 2280 PCIe Gen4 x4 (for NVMe SSD caching or storage pools) |
| USB Ports | 1 x USB 3.2 Gen2 Type-C (10 Gbps), 2 x USB 3.2 Gen2 Type-A (10 Gbps) |
| Drive Bays | 6 x 3.5-inch hot-swap bays |
| Description | The QNAP TVS-h674-i5-32G is a high-performance 6-bay tower NAS designed for SMBs and virtualization environments. Powered by an Intel Core i5-12400 6-core/12-thread processor with Intel UHD Graphics 730 and 32GB DDR4 (2 x 16GB, expandable to 64GB), it runs the ZFS-based QuTS hero OS to provide data integrity with block-level inline deduplication, compression, near-limitless snapshots, SnapSync and SSD optimization. The system offers PCIe Gen4 expandability (one x16 and one x4 slot), two M.2 NVMe PCIe Gen4 x4 slots for caching or SSD pools, dual 2.5GbE network ports for accelerated file sharing, multiple USB 3.2 Gen2 ports (Type-C and Type-A), and HDMI 1.4b output (up to 4K @ 30Hz) for local display and 4K playback/transcoding. Diskless (no drives included) with hot-swap 3.5" bays, AES-NI encryption, hardware transcoding and a suite of enterprise features for backup, virtualization and media workflows. |
| Form Factor | Tower |
| HDMI Output | 1 x HDMI 1.4b (up to 4096 x 2160 @ 30Hz) |
| Memory Type | DDR4 SODIMM |
| Flash Memory | 5 GB (dual-boot OS protection) |
| Key Features | ZFS-based QuTS hero OS with block-level inline deduplication, compression and near-limitless snapshots PCIe Gen4 expandability for high-speed NICs and accelerators Dual M.2 PCIe Gen4 NVMe slots for cache acceleration or SSD pools Dual 2.5GbE ports for accelerated file sharing and large file transfers Hardware transcoding and HDMI output for local 4K playback (HDMI 1.4b, 4K @30Hz) AES-NI hardware encryption Supports virtualization, snapshot-based recovery, SSD cache/RAID features and enterprise NAS services |
| Manufacturer | QNAP |
| Power Supply | 250 W, 100-240 V |
| Product Line | TVS-h674 |
| Weight (Net) | 14.45 lbs |
| Product Title | QNAP TVS-h674-i5-32G 6-Bay ZFS NAS - Intel Core i5-12400, 32GB DDR4, Dual 2.5GbE, PCIe Gen4, 2x M.2 NVMe (Diskless) |
| LED Indicators | HDD 1-6, Status, LAN, USB, M.2 |
| Maximum Memory | 64 GB (2 x 32 GB SODIMM) |
| PCIe Expansion | 2 slots: Slot 1 PCIe Gen4 x16, Slot 2 PCIe Gen4 x4 (supports add-in NICs, including 10/25GbE cards) |
| SATA Interface | SATA III (6 Gb/s) / SATA II (3 Gb/s) supported |
| Included Drives | Diskless (no drives included) |
| Additional Notes | Supports installation of wider PCIe cards if adjacent PCIe slot is not used; product images and specifications subject to change by manufacturer. |
| CPU Architecture | 64-bit x86 |
| Installed Memory | 32 GB DDR4 (2 x 16 GB SODIMM) |
| Operating System | QuTS hero (ZFS-based) |
| Package Contents | TVS-h674 storage system (diskless) 1 x Ethernet cable 1 x Power cord 2 x M.2 SSD heatsinks 24 x Flat head screws (for 3.5" HDD) 18 x Flat head screws (for 2.5" HDD/SSD) 2 x Drive tray keys Quick Installation Guide |
| Encryption Engine | AES-NI |
| Power Consumption | HDD Sleep Mode: 39.911 W Operating Mode (Typical, fully populated test): 79.363 W |
| Relative Humidity | 5 - 95% RH non-condensing (wet bulb: 27°C / 80.6°F) |
| Network Interfaces | 2 x 2.5 Gigabit Ethernet (supports 2.5G/1G/100M/10M) |
| Drive Compatibility | 3.5-inch SATA HDDs; 2.5-inch SATA HDDs/SSDs |
| Storage Temperature | -20 - 70°C (-4°F - 158°F) |
| Operating Temperature | 0 - 40°C (32°F - 104°F) |
| Dimensions (H x W x D) | 7.41 × 10.41 × 11.06 inches |
| Weight (Gross / Packaged) | 17.79 lbs |
| RAID and Storage Features (selected) | RAID expansion RAID hot spare RAID sync/rebuild/scrubbing SSD cache acceleration support SSD Cache RAID, SSD dedicated ZIL cache Shared Folder Data Deduplication and Compression Self-healing, silent error detection |
QNAP TVS-h674-i5-32G,6-bay QuTS hero NAS, Intel Core i5-12400 6-core/12-thread, up to 4.6GHz, 32GB SO-DIMM DDR4(max.128GB), 6 x 2.5"/3.5" SATA HDD/SSD, 3 Yrs
