Startech Usb-c / Usb 3.0 Docking Station - Universal Laptop Docking Station - Dual 4k - Dual DK30A2DH
QUICK OVERVIEW
Overview
This dual-4K USB 3.0 docking station is the next generation in USB universal docking stations, working with both USB-C and USB-A port equipped laptops and supporting multiple combinations of Ultra HD 4K DisplayPort and HDMI monitors.
It’s Mac and Windows® compatible, making it the ideal accessory for your MacBook Pro, Dell XPS or other laptop.
Enhance productivity with a dual-4K video workstation
This dual-4K docking station helps improve your productivity by expanding the display capabilities of your laptop across two Ultra HD 4K monitors -- even if your laptop doesn't natively support 4K output. The docking station supports 4K low latency, high-resolution graphics on both video ports, using any combination of HDMI® or DisplayPort monitors.
With the dual-4K dock, you can connect:
- 2x 4K DisplayPort displays at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz
-
2x 4K HDMI displays at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz
-
1x 4K DisplayPort + 4K HDMI displays at 4096 x 2160 resolution @ 60Hz / 3840 x 2160 @ 60Hz
The docking station is ideal for producers, graphic and web designers, engineers, architects and many other professionals who work on advanced graphics applications. It offers a fast and easy way to maximize your laptop’s workable screen space, giving you three screens in total when coupled with your laptop’s display.
The truly universal docking station
Compatible with both Windows and MacBook computers, this universal laptop dock supports DisplayLink® technology and works with USB-C and USB-A enabled laptops. This means you can connect newer USB-C or Thunderbolt™ 3 laptops or extend the life of legacy USB 3.0 (Type-A) laptops. DisplayLink graphics technology works across computing platforms and connector types to provide a universal multi-display docking solution. The USB-C connector works seamlessly with DisplayLink to support high-resolution monitors, enabling two full 4Kp60 displays from a single USB connection.
With its universal interface, the docking station can enable a single desktop setup to support different users at different times, no matter what type of computer or device is being used. The universal docking station allows one docking station to be used throughout the organization, for use with the latest Ultrabook™ and MacBook laptops, and Windows Pro tablets as well as older devices.
Providing both full backward compatibility and future proofing, it is the ultimate docking station solution for offices with mixed laptop deployment.
All the connections you need
This USB 3.0 docking station lets you connect the peripherals you need, to transform your laptop into a powerful, fully capable workstation. With six USB 3.0 ports (USB Type-A), a Gigabit Ethernet port, plus separate 3.5 mm audio and microphone ports for multiple audio, you have all the connections you need to maximize performance.
To add laptop charging support for USB-C-equipped laptops, simply add the StarTech.com HB30C1A1CPD USB to USB-C adapter to extend this dock’s versatility.
The DK30A2DH is backed by a StarTech.com 3-year warranty and free lifetime technical support.
Hardware | |
Bus Type | USB-C |
Chipset ID | DisplayLink - DL-6950 VIA/VLI - VL813 |
Displays Supported | 2 |
Fast-Charge Port(s) | Yes |
Industry Standards | USB Battery Charging Specification Rev. 1.2 IEEE 802.3, IEEE 802.3u, IEEE 802.3ab USB 3.0 - Backward compatible with USB 2.0/1.1 |
Indicators | |
LED Indicators | Power |
Packaging Information | |
Shipping (Package) Weight | 851 g [30 oz] |
Performance | |
Auto MDIX | Yes |
Compatible Networks | 10/100/1000 Mbps |
Full Duplex Support | Yes |
Maximum Data Transfer Rate | 5 Gbps (USB 3.0) 2 Gbps (Ethernet; Full-Duplex) |
Maximum Digital Resolutions | Single display - DisplayPort - 4096 x 2160 @ 60Hz / 3840 x 2160 @ 60Hz Single Display - HDMI - 4096 x 2160 @ 60Hz / 3840 x 2160 @ 60Hz Dual displays - DisplayPort and HDMI - 4096 x 2160 @ 60Hz / 3840 x 2160 @ 60Hz |
Type and Rate | USB 3.0 - 5 Gbit/s |
UASP Support | Yes |
Physical Characteristics | |
Cable Length | 152.4 mm [6 in] |
Color | Black & Silver |
Enclosure Type | Aluminum and Plastic |
Product Height | 28 mm [1.1 in] |
Product Length | 226 mm [8.9 in] |
Product Weight | 301 g [10.6 oz] |
Product Width | 87 mm [3.4 in] |
Power | |
Center Tip Polarity | Positive |
Input Current | 1 A |
Input Voltage | 100 ~ 240 AC |
Output Current | 2 A |
Output Voltage | 20V DC |
Plug Type | N |
Power Consumption (In Watts) | 40W |
Power Source | AC Adapter Included |
Software | |
OS Compatibility | Windows? 7, 8, 8.1, 10 macOS 10.11 to 10.13 |
Special Notes / Requirements | |
Note | 4K resolution is supported on both video ports. A 4K-capable DisplayPort or HDMI display is required to achieve 4Kx2K resolution |
A USB-C to USB-C cable and a USB-C to USB-A cable are included. | |
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity standard offers speeds up to 5Gbps. | |
Hardware | |
Bus Type | USB 3.0 |
4K Support | Yes |
Environmental | |
Storage Temperature | -10?C to 70?C (14?F to 158?F) |
Operating Temperature | 0?C to 40?C (32?F to 104?F) |
Humidity | 10~90% RH |
Connector(s) | |
Connector Type(s) | USB Type-C (24 pin) USB 3.0 Female |
Microphone Jack | |
HDMI Female | |
Ethernet Gigabit Female | |
DisplayPort Female | |
9 pin USB 3.0 A Female | |
3.5 mm Audio | |
Special Notes / Requirements | |
System and Cable Requirements | A host laptop with an available USB-C port or a USB-A port. |
What's in the Box | |
Included in Package | 1 m USB-C to USB-A cable |
1 m USB-C to USB-C cable | |
docking station | |
quick-start guide | |
universal power adapter (NA/JP, UK, EU, ANZ) |
Marketing Text | This dual-4K USB 3.0 docking station is the next generation in USB universal docking stations, working with both USB-C and USB-A port equipped laptops and supporting multiple combinations of Ultra HD 4K DisplayPort and HDMI monitors. |
PI Date | Jan 2018 |
Brand Name | Startech |
Manufacturer Web Site | http://www.startech.com |
Product Type | Docking Station |
Depth (mm) | 226.0 |
Height (mm) | 28.0 |
Width (mm) | 87.0 |
Weight (Grams) | 301.0 |
Colour | Black and Silver |
Operating Temperature | 0 to 40°C |
Other Features | * Auto MDIX: Yes * Compatible Networks: 10/100/1000 Mbps * Full Duplex Support: Yes |
System Requirements | * A host laptop with an available USB-C port or a USB-A port. |
Package Contents | * 1 - docking station * 1 - 1 m USB-C to USB-A cable * 1 - 1 m USB-C to USB-C cable * 1 - quick-start guide |
Warranty Information | 3 Years |
