Winstar Wireless Ac1300m Dual Band Usb 3.0 Adapter Usbwin688u3

SKU
243389
Brand
MPN
USBWIN688U3
Warranty
Standard Manufacturer's Warranty
Availability
In stock
Freight Estimate
Special Price $34.00 Regular Price $39.00
Buy Now And Earn 34 Reward Points!

Features

  • 1300 (867+400)Mbps wireless speed
  • Support 2.4GHz & 5GHz WLAN networks
  • Dual Band connections for lag-free HD video streaming and gaming
  • SuperSpeed USB 3.0 port, backward compatible to USB 2.0
  • Complies with IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
  • 20MHz & 40MHz & 80MHz bandwidth transmission
  • OFDM with BPSK, QPSK, 16QAM, 64QAM, 256QAMmodulation
  • Supports Windows XP / Vista / 7 / 8 / 8.1/10, MAC

Specification

  • Hardware
    • Ports: USB 3.0
    • Button: WPS
    • LED: 1 X Link/ Active
    • Chipset:RTL8812AU
    • Flash: N/A
    • SDRAM: N/A
    • Power Supply: USB 5V
    • Power Plug: N/A
    • Power Consumption:/
    • Rated Voltage/ requency /current:DC 5V about 500mA
  • Wireless
    • Standard:IEEE802.11ac,IEEE 802.11a, IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
    • Modulation:
      • 11ac\n: 16QAM, 64QAM 128QAM 256QAM with OFDM
      • 11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
      • 11b: DQPSK, DBPSK, DSSS, CCK
    • Speed:
      • 802.11ac: up to 867Mbps
      • 802.11n: up to 400Mbps
      • 802.11a: up to 54Mbps
      • 802.11g: 54 M
      • 802.11b: 11 M
    • Frequency band:5GHz and 2.4GHz
    • Power:
      • 802.11b: 22dBm ± 2 dBm 802.11g: 16dBm ± 2 dBm
      • 802.11n: 15dBm ± 2 dBm 802.11ac: 14dBm ± 2 dBm
    • Distance:Outdoors 300m, Indoor 100m(According to the actual environment change)
    • Safely 64/128-bit WEP, AES,TKIP,WPA,WPA2,802.1x,WPA-PSK,WPA2-PSK,MAC, WDS
  • Environmental
    • Operating Temperature:0ºC~40ºC
    • Storage Temperature:-10~70℃
    • Relative Humidity(Operational): 10%~90%,noncondensing
    • Relative Humidity(Storage):10%~90%,noncondensing
  • Software
    • Standard Version
      • RFC768 User Datagram Protocol(UDP)
      • RFC791 Internet Protocol(IP)
      • RFC792 Internet Control Message Protocol
      • RFC793 Transmission Control Protocol(TCP)
      • bandwidth:20MHz、40MHz、80MHz
      • Wireless Mode:11ac only, 11n only, 11g only、11b only(option)
    • System Windows XP / Vista / 7 / 8 / 8.1/10, MAC

Product weight and dimensions

Item Weight: 0.25 KG
Product Dimensions: 98mm L x 28mm W x 10mm (L x W x H)

Package content

  • 1 x Wireless-AC USB3.0 Aapter
  • 1 x Quick Installation
  • 1 x CD driver

Features

  • 1300 (867+400)Mbps wireless speed
  • Support 2.4GHz & 5GHz WLAN networks
  • Dual Band connections for lag-free HD video streaming and gaming
  • SuperSpeed USB 3.0 port, backward compatible to USB 2.0
  • Complies with IEEE 802.11ac, IEEE 802.11n, IEEE 802.11g, IEEE 802.11b standards
  • 20MHz & 40MHz & 80MHz bandwidth transmission
  • OFDM with BPSK, QPSK, 16QAM, 64QAM, 256QAMmodulation
  • Supports Windows XP / Vista / 7 / 8 / 8.1/10, MAC

Specification

  • Hardware
    • Ports: USB 3.0
    • Button: WPS
    • LED: 1 X Link/ Active
    • Chipset:RTL8812AU
    • Flash: N/A
    • SDRAM: N/A
    • Power Supply: USB 5V
    • Power Plug: N/A
    • Power Consumption:/
    • Rated Voltage/ requency /current:DC 5V about 500mA
  • Wireless
    • Standard:IEEE802.11ac,IEEE 802.11a, IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
    • Modulation:
      • 11ac: 16QAM, 64QAM 128QAM 256QAM with OFDM
      • 11g: BPSK, QPSK, 16QAM, 64QAM, OFDM
      • 11b: DQPSK, DBPSK, DSSS, CCK
    • Speed:
      • 802.11ac: up to 867Mbps
      • 802.11n: up to 400Mbps
      • 802.11a: up to 54Mbps
      • 802.11g: 54 M
      • 802.11b: 11 M
    • Frequency band:5GHz and 2.4GHz
    • Power:
      • 802.11b: 22dBm ± 2 dBm 802.11g: 16dBm ± 2 dBm
      • 802.11n: 15dBm ± 2 dBm 802.11ac: 14dBm ± 2 dBm
    • Distance:Outdoors 300m, Indoor 100m(According to the actual environment change)
    • Safely 64/128-bit WEP, AES,TKIP,WPA,WPA2,802.1x,WPA-PSK,WPA2-PSK,MAC, WDS
  • Environmental
    • Operating Temperature:0ºC~40ºC
    • Storage Temperature:-10~70℃
    • Relative Humidity(Operational): 10%~90%,noncondensing
    • Relative Humidity(Storage):10%~90%,noncondensing
  • Software
    • Standard Version
      • RFC768 User Datagram Protocol(UDP)
      • RFC791 Internet Protocol(IP)
      • RFC792 Internet Control Message Protocol
      • RFC793 Transmission Control Protocol(TCP)
      • bandwidth:20MHz、40MHz、80MHz
      • Wireless Mode:11ac only, 11n only, 11g only、11b only(option)
    • System Windows XP / Vista / 7 / 8 / 8.1/10, MAC

Product weight and dimensions

Item Weight: 0.25 KG
Product Dimensions: 98mm L x 28mm W x 10mm (L x W x H)

Package content

  • 1 x Wireless-AC USB3.0 Aapter
  • 1 x Quick Installation
  • 1 x CD driver
