Benefits
Field upgrade kit for new and legacy High-Traffic Vertical Lifts
Compliant with NFPA 101-2006 18.2.3 & 19.2.3, which states that anything mounted in a hospital hallway must not protrude over 6 inches (15 cm) from the wall
Single SKU includes all color options (white, black and grey)
Easy to install
Durable, easy-to-clean exterior
Two adjustment options: Full auto-retraction?keyboard retracts immediately after use; manual initialization?auto-retract feature can be calibrated so lift only occurs with manual intervention
Tech Specs
Part Number: 97-487-800
Description: Vertical Lift Auto-Retracting Keyboard Kit (black, white or grey)
Includes keyboard tray lift assembly, wrist rest, multiple covers (grey, black, white), Velcro and adhesive strips
Compatible with the following Vertical Lift part numbers: 60-593-216, 60-593-195, 25-022-100, 25-022-101
Kit uses existing keyboard tray from the Vertical Lift
Compliant with NFPA 101-2006 18.2.3 & 19.2.3: anything mounted in hospital hallways must not protrude over 6 inches (152 mm) from the wall
Weight Capacity: 0.75 to 2.5 lbs (0.34 to 1.13 kg). Includes weight of keyboard, mouse, mouse pad, wrist rest and adhesive materials
Monitor height should not exceed 15.75 inches (400 mm), assuming VESA hole pattern is centered on the monitor
Keyboard depth should not exceed 7 inches (178 mm)
Kit allows ergonomic negative-tilt of keyboard tray, ensuring wrists remain in a neutral position during data entry
Shipping Dimensions: 4.5"H x 17"W x 11"D (114 x 432 x 279 mm)
Shipping Weight: 4.9 lbs (2.2 kg)
Warranty: Five (5) years
