Hd Interactive Arm LCD Wall Mount 45-296-026
SKU
245221
Brand
MPN
45-296-026
Warranty
Standard Manufacturer's Warranty
$425.00
Buy Now And Earn 425 Reward Points!
QUICK OVERVIEW
18.2KG 45-296-026
Accommodate active TV positioning. Lift, swing or turn your display in any direction! Features 20 inches (51 cm) of vertical adjustment and 180° motion to either side. Now anyone can effortlessly move a TV or heavy monitor into multiple positions with only a light touch. Your screen will seemingly float on air, being easily adjusted between standing and seated heights. No more awkward viewing angles and sore necks.
| Application/Usage | Gaming, Wall |
| Product Type | Mounting Arm |
| Device Supported | TV, Monitor, Display |
| Features | Tilt, Rotate, Swing, Retractable, Pivot, Pan, Heavy Duty, Extendable, Ergonomic, Cable Management, Adjustable, Vertical Adjustment |
| Maximum Load Capacity | 18.14 kg |
| Brand Name | Ergotron |
| Minimum Screen Size Supported | 76.2 cm |
| Maximum Screen Size Supported | 165.1 cm (65") |
| VESA Mount Compatible | Yes |
| Product Family | Interactive |
| Mounting Pattern | 200 x 100, 200 x 600, 200 x 400 |
| Product Color | Polished Aluminum |
| Color Family | Grey |
| Minimum Load Capacity | 8.16 kg |
| Mount Function | Tilt, Wall Mount, Rotate, Pivot, Pan, Extendable, Cable Management, Adjustable |
| Mount Surface | Wall |
| Manufacturer Part Number | 45296026 |
| Manufacturer Website Address | http://www.ergotron.com/Home/tabid/36/language/en-AU/Default.aspx |
| Manufacturer | Ergotron, Inc |
| Product Name | Interactive Arm, HD |
| Product Line | Interactive |
| Additional Information | • Lift: 20" • Tilt: 25° • Pan: 180° • Rotation: 10° • Patented Constant Force technology enables light-touch adjustments • Extends 24" from wall when in use and can be fully retracted to 5.5" when not in use • Provides smooth, continuous vertical and horizontal movement of the TV/display in all directions • Gravity pivot enables tilting capabilities without the need of knobs or levers • Improves ergonomic viewing for TVs/displays mounted high on the wall • Tilt and pan for maximum viewing flexibility • Level the screen at any position with +/- 5º of post-installation rotation • Cable management clips on the underside of the arm route and hide wires • Easy to use: simple installation and effortless operation |
| Weight (Approximate) | 8.39 kg |
| Form Factor | Wall Mountable |
| Minimum Tilt Angle | -10° |
| Maximum Tilt Angle | 15° |
| Height Adjustable | Yes |
| Minimum Rotate Angle | -5° |
| Maximum Rotate Angle | 5° |
| Maximum Pan Angle | 180° |
| Shipping Dimensions | Height 19.8, Width 30.4, Length 66.2, Shipping Weight 9.78 KG |
HD INTERACTIVE ARM LCD WALL MOUNT
