TC53 LAN 6.0IN Display Wifi 6E 8GB RAM/64Gb Rom SE4720 Imager 3.5MM Headphone Jack 8MP Ffc 16MP Rfc Warm Swap 4680 Mah Standard Battery Gms Row Only TC5301-0T1E7B1000-A6

SKU
418074
Brand
MPN
TC5301-0T1E7B1000-A6
Warranty
Standard Manufacturer's Warranty
Availability
Preorder (Contact Us)
Freight Estimate
$3,440.00
Buy Now And Earn 3440 Reward Points!
POWERING A NEW GENERATION OF DATA COLLECTION

Introducing the TC53 and TC58, the first members of a new generation of Zebra mobile computers designed to do more. What makes these devices so different? New hardware redefines mobile computing performance. New solutions and sensor technologies redefine the world of possibilities - from mobile payment to parcel dimensioning. All the latest wireless technologies give workers faster and more reliable access to information they need to get the job done - including 5G, Wi-Fi 6E and CBRS (US only). A class-leading 6-inch screen lets workers see more, do more - and scroll less. Zebra-only Mobility DNA TM tools deliver built-in advantage, maximizing user productivity while minimizing IT complexities throughout the entire device lifecycle. New manufacturing technologies make the TC53 and TC58 thinner - yet even more rugged. The result? A new generation of data collection. A new level of operational efficiency. And a new level of workforce productivity. The TC53/TC58 - driving new possibilities into the world of mobility.

Give your workers the fastest speeds with Wi-Fi 6E and 5G. And support for CBRS private LTE networks enables cost-effective wireless connectivity in the largest indoor and outdoor facilities.

Industry-leading 6-inch advanced display

Get the largest, highest resolution and brightest display in this product class. Screens are easy to read indoors and outside. Edge-to-edge technology means more information and less scrolling. It works when wet. And workers can use a stylus or finger, with or without a glove - no need to change modes.

Thinner and tougher

An ergonomic design and advanced manufacturing and materials technology make the TC53 and TC58 thinner, yet rugged.

Unmatched battery technology

Get full shift power and the intelligence to better manage batteries with Zebra's PowerPrecision+ standard 4680 mAh and extended 7000 mAh batteries.

Hear every word on every call

With three integrated microphones, two speakers and support for wireless and wired headsets, collaboration is easy.

Capture ultra-high resolution photos and video intelligence

The 16 MP integrated camera offers the highest resolution in its class. And with optional Optical Image Stabilization (OIS), it's easy to capture sharp, detailed photographs to document proof of condition, proof of delivery and more.Inside your facility, optional Push-to-Talk (PTT) Express enables instant PTT walkie-talkie style calls over the Wi-Fi network, right out of the box. Out in the field, optional PTT Pro enables PTT calling and secure messaging over the cellular network through an easy-to-deploy cost-effective subscription service.

Add PBX handset functionality

Add fully-featured PBX handset functionality with Zebra's Workforce Connect Voice. The need to purchase and manage additional voice-enabled devices is eliminated. And a custom interface makes it easy to execute even the most complex telephony features.

DRIVE WORKFORCE PRODUCTIVITY AND DEVICE VALUE TO A NEW LEVEL WITH MOBILITY DNA

Simplify device integration

Create rich apps that take full advantage of your device's capabilities with Enterprise Mobility Management Tool Kit. Build feature-rich web applications with Enterprise Browser. And easily capture and integrate barcode data into your apps without writing any code with DataWedge API.

Increase device security

Keep your devices secure every day they are in service with LifeGuard TM for Android TM 2 . And restrict apps and device features with Enterprise Home Screen.

Deploy devices quickly and easily <
Product Type Handheld Terminal
Flash Memory 64 GB
Screen Resolution 1080 x 2160
Standard Memory 8 GB
Operating System Android
Connectivity Technology Wireless
Form Factor Phone-size
Processor Speed 2.70 GHz
Screen Size 6"
Brand Name Zebra
Scanning Distance 12.19 m
Screen Mode Full HD
Memory Card Supported microSD
Processor Model 6490
Processor Core Octa-core (8 Core)
Touchscreen Yes
Battery Included Yes
Bluetooth Yes
Wireless LAN Yes
Scanner Range Long Range
Wireless LAN Standard IEEE 802.11 a/b/g/n/ac/d/h/i/r/k/v/w/mc/ax
Bluetooth Standard Bluetooth 5.2
Image Sensor Type Imager
Rear Camera Yes
Front Camera Yes
TAA Compliant Yes
Near Field Communication (NFC) Yes
Ingress Protection (IP) Rating IP65, IP68
Rugged Yes
Google Mobile Services (GMS) Yes
Scan Engine Model SE4720
Scanning Capability 1D, 2D
Battery Chemistry Lithium Ion (Li-Ion)
Battery Capacity 4400 mAh
Removable Battery Yes
Rear Camera Resolution 16 Megapixel
Front Camera Resolution 8 Megapixel
Display Screen Type LED
Manufacturer Part Number TC53010T1E7B1000A6
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model TC53
Product Name TC53 Handheld Terminal
USB Yes
USB Type-C Yes
Buttons & Keys Programmable buttons for maximum flexibility: dual dedicated scan buttons, dedicated push-totalk button, volume up/down buttons and trigger button of trigger handle via Back I/O.
Application/Usage Field Sales/Service, Logistics, Transportation, Retail
Global Navigation Satellite System (GNSS) Supported BeiDou/Galileo/GLONASS
Length 164.6 mm
Height 16.8 mm
Width 77.2 mm
Weight (With Battery) 293 g
Power Source Battery
Upgradable Operating System Android 16
Brightness 600 cd/m²
Features Push-to-talk, Gorilla Glass, Water Resistant
Sensor Type Gyroscope, Proximity, Pressure Sensor, Motion Sensor, Magnetometer, Light Sensor, Accelerometer, eCompass
Drop Specification • Multiple 6 ft./1.8 m drops to concrete over operating temp (-20°C to 50°C/-4°F to 122°F) with protective boot per MIL STD 810H; • Multiple 5 ft./1.5 m drops to tile over concrete (-10°C to 50°C/14°F to 122°F) per MIL STD 810H
Wireless Charging Yes
Multi-touch Screen Yes
Additional Warranty Information Subject to the terms of Zebra's hardware warranty statement, the TC53/TC58 is warranted against defects in workmanship and materials for a period of 1 (one) year from the date of shipment.
Shipping Dimensions Height 5.2, Width 10.5, Length 21.2, Shipping Weight 0.44 KG
TC53 LAN 6.0IN DISPLAY WIFI 6E 8GB RAM/64GB ROM SE4720 IMAGER 3.5MM HEADPHONE JACK 8MP FFC 16MP RFC WARM SWAP 4680 MAH STANDARD BATTERY GMS ROW ONLY
