Zebra DIRECT THERMAL PRINTER ZD621 HEALTHCARE COLOR TOUCH LCD 203 DPI USB USB HOST ETHERNET SERIAL BTLE5 APAC CORD BUNDLE EU UK AUS JP SWISS FONT EZPL ZD6AH42-D0PF00EZ

SKU
388014
Brand
MPN
ZD6AH42-D0PF00EZ
Warranty
Standard Manufacturer's Warranty
Availability
Preorder (Contact Us)
Freight Estimate
$994.00
Buy Now And Earn 994 Reward Points!

DIRECT THERMAL PRINTER ZD621 HEALTHCARE COLOR TOUCH LCD 203 DPI USB USB HOST ETHERNET SERIAL BTLE5 APAC CORD BUNDLE EU UK AUS JP SWISS FONT EZPL

ELEVATE YOUR EXPECTATIONS WITH ZEBRA'S ADVANCED HEALTHCARE DESKTOP PRINTERS

You need a reliable printer built for healthcare that delivers quality performance, now and for years to come. It needs key features, and be easy to setup, operate, manage and maintain-onsite or remotely. It needs to be secure to protect patient information, whether integrated onto your network or not, to prevent downtime and costly cyberattacks. You need it, and Zebra delivers it, for more than 50 years. We've engineered our healthcare printers to match your workflows for hassle-free performance. Building on the legacy of Zebra's GK Series and ZD420 healthcare printers, the ZD421 delivers the flexibility and reliability you need, with even more capabilities and security, to set you up for years of use.

IT'S TIME TO ADVANCE

Migrate from G to Z

The ZD421 builds on the legacy of Zebra's GK Series and ZD420 Series printers, offering you the functions and capabilities of its predecessor-and much more. The next-generation ZD421 leverages this heritage to deliver advanced features for a new era of intelligence and forward flexibility, packaged in a ready-to-work healthcare model.

ADVANCE YOUR HEALTHCARE WORKFLOWS

Easy to Clean, Sanitize and Safely Power

Disinfectant-ready plastics, UV-resistant housing and a sealed-button interface make the ZD421 healthcare printer easy to clean and sanitize, helping prevent the spread of infections in hospitals and clinics. And, the power supply is IEC 60601-1 compliant for use in healthcare facilities.

SIMPLE TO USE

Intuitive and Powerful Operation

The ZD421 offers new, advanced features that make it stand apart. It includes a new, more intuitive user interface, powerful architecture and field-upgradeable wireless kit. It also has new media guide and media handling designs that make daily operation even easier.

SUPPORTS NEARLY EVERY USE CASE

Multiple Models to Match Your Needs

Available in direct thermal, thermal transfer and ribbon cartridge models, all specifically for healthcare, the ZD421 healthcare printer meets a wide variety of healthcare-specific use cases and requirements.

READY FOR NOW AND WHAT'S NEXT

Get Years of Printing Performance

Featuring an innovative architecture, the ZD421 is engineered to power future printing. It's 30% more powerful than the ZD420 Series and 700% more than the GK Series. Perform more operations simultaneously, maintain security and be ready for what's next.

Backwards Compatible with Virtually Any Existing Printer

Deploy your ZD421 into your existing printer fleet with confidence. Use the same label formats and applications you're using today. It supports both EPL and ZPL printer languages, and can emulate languages normally associated with other printer brands using Zebra's Print DNA tool, Virtual Devices.


Features
  • Print methods: Thermal Transfer or Direct Thermal
  • ZPL and EPL programming languages
  • 5 status icon, 3 button user interface
  • USB 2.0, USB Host
  • Printer setup mobile app for Android and iOS via BLE (Bluetooth Low Energy 5) connection
  • Real Time Clock (RTC)
  • OpenACCESS™ for easy media loading
  • Dual-wall frame construction
  • ENERGY STAR® certified
Memory
Standard Memory 256 MB
Warranty
Limited Warranty 2 Year
Interfaces/Ports
USB Yes
Serial Port Yes
USB Host Yes
Network & Communication
Bluetooth Yes
Ethernet Yes
Ethernet Technology Ethernet
Power Description
Input Voltage 230 V AC
120 V AC
Power Source AC Supply
Technical Information
Application/Usage Desktop
Barcode Symbology Supported Code 49
UPC-E
Standard 2 of 5
Micro PDF
Plessey
EAN With 2 or 5 Digit Extension
LOGMARS
QR Code
Interleaved 2 of 5
EAN-13
Code 11
Data Matrix
Codablock
MSI
ISBT-128
AZTEC
POSTNET
Planet Code
Industrial 2 of 5
UPC 2 or 5 Digit Extension
Code 93
Maxi Code
Code 39
UPC-A
Codabar
EAN-8
PDF417
Code 128
Maximum Print Width 104 mm (4.09")
Recommended Use Label/Receipt Print
Connectivity Technology Wired
Features UV Resistant Housing
Status Indicator
Dual Wall Frame
Maximum Mono Print Speed 152 mm/s
Mobile Device Printing Yes
Print Color Capability Monochrome
Optional Connectivity Wireless LAN
Real Time Clock Yes
Maximum Print Resolution (dpi) 203
Environmental Conditions
Storage Relative Humidity 5% - 95%
Storage Temperature -40°C - 60°C
Operating Temperature 4.4°C - 40.6°C
Operating Relative Humidity 10% - 90%
Fonts & Emulation
Language Emulation ZPL II
XML
EPL2
ZBI
Physical Characteristics
Weight (Approximate) 2.05 kg
Form Factor Portable
Height 189 mm
Width 203.2 mm
Depth 266.7 mm
General Information
Product Type Thermal Transfer Printer
Manufacturer Part Number ZD6AH42-D0PF00EZ
Manufacturer Website Address http://www.zebra.com/ap/en.html
Manufacturer Zebra Technologies Corporation
Product Model ZD421-HC
Product Name ZD421-HC Thermal Transfer Printer
Brand Name Zebra
Miscellaneous
Package Contents
  • ZD421-HC Thermal Transfer Printer
  • Empty Ribbon Take-UP Cores (1 in. and 0.5 in.)
  • 2 x 300 m Ribbon Core Adapters for Non-Zebra Ribbon
  • AC Power Supply
  • Power Cord(s)
  • USB Cable
  • Quick Start Guide
  • Regulatory Guide
Platform Supported PC
iOS
Android
Environmentally Friendly Yes
Environmental Certification RoHS
Cables Included USB
AC
Energy Star Yes
Power Cable Localization UK
JP
EU
AUS
Media Types & Handling
Media Thickness 4826 µm
Maximum Roll Diameter 127 mm
Media Type Die-cut Label
Continuous Label
Continuous Receipt
Tag Stock
Fanfold
Roll Fed
Wristband
Label
Media Sensor Full Width Sensor
Multi-position Transmissive/Gap Sensor
Moveable Reflective/Black Mark Sensor
Maximum Label Width 112 mm
Maximum Label Length 991 mm
